MECHANISM TROUBLESHOOTING GUIDE
C.
AUTO STOP.
(PLAY/CUE/REV)
In Play/Cue/Rev, Is the Pinch
Roller in contact with the
Capstan Shaft?
YES
Are there T/up and Supply Reel
pulses.
YES
Check the Syscon, µ-COM.
D.
Cassette doesn't load.
Insert the cassette.
YES
Does the Lever Assembly S/W
work normally?
YES
Is there variation for CST IN S/W
Output?
(In Tape with REC Tab
"L"→"H"→"L")
(In Tape without REC Tab
"L"→"H"→"L"→"H")
YES
Check the Syscon Circuit.
Check alignment positions
(page 4-13).
Is the output of DFG, DPG OK?
NO
YES
NO
Check the Servo, Syscon.
Replace the Reel Sensor.
NO
Check Lever Assembly S/W.
NO
Does the CST IN S/W work
normally?
YES
NO
Check the Syscon Circuit.
4-24
NO
Replace the Drum Motor.
NO
Replace the CST IN S/W.
