# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R554 NRSA63J 331X RESISTOR,METAL GLAZED(CHIP)
R555 NRSA6AD 221W RESISTOR,METAL GLAZED(CHIP)
R556 NRSA63J 223X RESISTOR,METAL GLAZED(CHIP)
R557 NRSA6AD 273W RESISTOR,METAL GLAZED(CHIP)
R558 NRSA63J 223X RESISTOR,METAL GLAZED(CHIP)
R559 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R560 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R561 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R562 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R563 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R564 NRSA6AD 273W RESISTOR,METAL GLAZED(CHIP)
R566 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R567 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R568 NRSA6AD 683W RESISTOR,METAL GLAZED(CHIP)
R569 NRSA63J 105X RESISTOR,METAL GLAZED(CHIP)
R570 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R575 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R576 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R577 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R578 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R579 NRSA63J 563X RESISTOR,METAL GLAZED(CHIP)
R582 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R583 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R589 NRSA63J 105X RESISTOR,METAL GLAZED(CHIP)
R591 NRSA63J 104X RESISTOR,METAL GLAZED(CHIP)
R592 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R593 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R5A2 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R5A3 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R5A5 NRSA6AD 474W RESISTOR,METAL GLAZED(CHIP)
R5B3 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5B4 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5B5 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R5C1 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5C5 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5C6 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5C7 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5C9 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R5F1 NRSA63J 563X RESISTOR,METAL GLAZED(CHIP)
R5F2 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R5F3 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R5F4 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R5K1 NRSA63J 681X RESISTOR,METAL GLAZED(CHIP)
R5K2 NRSA6AD 821W RESISTOR,METAL GLAZED(CHIP)
R5K3 NRSA63J 122X RESISTOR,METAL GLAZED(CHIP)
R5K4 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
R5K9 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R5L1 NRSA02D 331X RESISTOR,METAL GLAZED(CHIP)
R5L2 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5L3 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5L4 NRSA02D 331X RESISTOR,METAL GLAZED(CHIP)
R5P2 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R5P3 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R5R8 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R5S1 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R705 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R706 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R707 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R710 NRSA63J 332X RESISTOR,METAL GLAZED(CHIP)
R711 NRSA63J 332X RESISTOR,METAL GLAZED(CHIP)
R712 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R713 NRSA63J 562X RESISTOR,METAL GLAZED(CHIP)
R714 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R716 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R717 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R718 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R719 NRSA02D 472X RESISTOR,METAL GLAZED(CHIP)
R720 NRSA02D 472X RESISTOR,METAL GLAZED(CHIP)
R7M1 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R7M2 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R7M4 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R7M5 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R7V1 NRSA63J 105X RESISTOR,METAL GLAZED(CHIP)
R7V2 NRSA63J 104X RESISTOR,METAL GLAZED(CHIP)
R7V3 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R7V4 NRSA6AD 564W RESISTOR,METAL GLAZED(CHIP)
R7V5 NRSA63J 682X RESISTOR,METAL GLAZED(CHIP)
R7V6 NRSA6AD 564W RESISTOR,METAL GLAZED(CHIP)
R7V7 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R7V8 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R7V9 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R801 NRSA6AD 335W RESISTOR,METAL GLAZED(CHIP)
R802 NRSA6AD 333W RESISTOR,METAL GLAZED(CHIP)
R803 NRSA6AD 272W RESISTOR,METAL GLAZED(CHIP)
NSP:Not Service Parts
SPECIFICATION NSP
330 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 10 W 2012 5.00% D
22K OHM 1 / 16 W 1608 5.00% D
27K OHM 1 / 16 W 1608 5.00% D
22K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
27K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
68K OHM 1 / 16 W 1608 5.00% D
1M OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
56K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
1M OHM 1 / 16 W 1608 5.00% D
100K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
470K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
56K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
680 OHM 1 / 16 W 1608 5.00% D
820 OHM 1 / 16 W 1608 5.00% D
1.2K OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
330 OHM 1 / 10 W 2012 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
330 OHM 1 / 10 W 2012 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
3.3K OHM 1 / 16 W 1608 5.00% D
3.3K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
5.6K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 10 W 2012 5.00% D
4.7K OHM 1 / 10 W 2012 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
1M OHM 1 / 16 W 1608 5.00% D
100K OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
560K OHM 1 / 16 W 1608 5.00% D
6.8K OHM 1 / 16 W 1608 5.00% D
560K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
3.3M OHM 1 / 16 W 1608 5.00% D
33K OHM 1 / 16 W 1608 5.00% D
2.7K OHM 1 / 16 W 1608 5.00% D
# REF No. PART No. PART NAME, DESCRIPTION
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R804 NRSA6AD 393W RESISTOR,METAL GLAZED(CHIP)
R805 NRSA6AD 272W RESISTOR,METAL GLAZED(CHIP)
R806 NRSA6AD 333W RESISTOR,METAL GLAZED(CHIP)
R807 NRSA63J 471X RESISTOR,METAL GLAZED(CHIP)
R808 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R809 NRSA6AD 183W RESISTOR,METAL GLAZED(CHIP)
R810 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R811 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R812 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R821 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R822 NRSA63J 104X RESISTOR,METAL GLAZED(CHIP)
R823 NRSA63J 222X RESISTOR,METAL GLAZED(CHIP)
R824 NRSA63J 104X RESISTOR,METAL GLAZED(CHIP)
R825 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R826 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R835 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R850 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R851 NRSA63J 101X RESISTOR,METAL GLAZED(CHIP)
R854 NRSA02D 681X RESISTOR,METAL GLAZED(CHIP)
R855 NRSA02D 681X RESISTOR,METAL GLAZED(CHIP)
R861 NRSA6AD 273W RESISTOR,METAL GLAZED(CHIP)
R862 NRSA6AD 273W RESISTOR,METAL GLAZED(CHIP)
R863 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R864 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R865 NRSA63J 105X RESISTOR,METAL GLAZED(CHIP)
R866 NRSA63J 331X RESISTOR,METAL GLAZED(CHIP)
R867 NRSA6AD 391W RESISTOR,METAL GLAZED(CHIP)
R868 NRSA02D 561X RESISTOR,METAL GLAZED(CHIP)
R871 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R874 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R875 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R876 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R877 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R8J3 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R901 NRSA63J 123X RESISTOR,METAL GLAZED(CHIP)
R902 NRSA63J 103X RESISTOR,METAL GLAZED(CHIP)
R903 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R904 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R905 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R906 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R907 NRSA63J 561X RESISTOR,METAL GLAZED(CHIP)
R908 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R909 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R910 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R911 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R913 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R914 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R919 NRSA63J 472X RESISTOR,METAL GLAZED(CHIP)
R920 NRSA63J 681X RESISTOR,METAL GLAZED(CHIP)
R921 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R922 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R923 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R924 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R925 NRSA63J 0R0X RESISTOR,METAL GLAZED(CHIP)
R927 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R928 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R929 NRSA63J 681X RESISTOR,METAL GLAZED(CHIP)
R930 NRSA63J 750X RESISTOR,METAL GLAZED(CHIP)
R931 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R932 NRSA63J 221X RESISTOR,METAL GLAZED(CHIP)
R933 NRSA63J 104X RESISTOR,METAL GLAZED(CHIP)
R934 NRSA63J 104X RESISTOR,METAL GLAZED(CHIP)
R935 NRSA63J 102X RESISTOR,METAL GLAZED(CHIP)
R937 NRSA63J 220X RESISTOR,METAL GLAZED(CHIP)
R938 NRSA63J 220X RESISTOR,METAL GLAZED(CHIP)
R940 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
R941 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
R942 NRSA63J 152X RESISTOR,METAL GLAZED(CHIP)
RS501 LG 6500RAB003A SENSOR
RS502 LG 6500RAB007A SENSOR
RS501 LG 6500RAB003A SENSOR
RS502 LG 6500RAB007A SENSOR
SC901 LG 6620RM0002J JACK,SCART
SW501 LG 556 213C SWITCH,DETECTOR
SW502 LG 556 213C SWITCH,DETECTOR
SW503 LG 556 213C SWITCH,DETECTOR
SW504 LG 556 213C SWITCH,DETECTOR
SW505 LG 556 213C SWITCH,DETECTOR
TU701 LG 6700PFPL06F TUNER
X501 LG 6212AA2100C RESONATOR,CRYSTAL
X501 LG 6202R31001F RESONATOR,CRYSTAL
X502 QAX0444 001 RESONATOR,CRYSTAL
X502 LG 6212AC2327E RESONATOR,CRYSTAL
X751 LG 529 021Q RESONATOR,CRYSTAL
SPECIFICATION NSP
39K OHM 1 / 16 W 1608 5.00% D
2.7K OHM 1 / 16 W 1608 5.00% D
33K OHM 1 / 16 W 1608 5.00% D
470 OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
18K OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
100K OHM 1 / 16 W 1608 5.00% D
2.2K OHM 1 / 16 W 1608 5.00% D
100K OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
100 OHM 1 / 16 W 1608 5.00% D
680 OHM 1 / 10 W 2012 5.00% D
680 OHM 1 / 10 W 2012 5.00% D
27K OHM 1 / 16 W 1608 5.00% D
27K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
1M OHM 1 / 16 W 1608 5.00% D
330 OHM 1 / 16 W 1608 5.00% D
390 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 10 W 2012 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
12K OHM 1 / 16 W 1608 5.00% D
10K OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
560 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
4.7K OHM 1 / 16 W 1608 5.00% D
680 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
0 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
680 OHM 1 / 16 W 1608 5.00% D
75 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
220 OHM 1 / 16 W 1608 5.00% D
100K OHM 1 / 16 W 1608 5.00% D
100K OHM 1 / 16 W 1608 5.00% D
1K OHM 1 / 16 W 1608 5.00% D
22 OHM 1 / 16 W 1608 5.00% D
22 OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
1.5K OHM 1 / 16 W 1608 5.00% D
SG 260 KODENSHI D33 REEL SENSO
GP1S566V SHARP REEL SENSOR OF
SG 260 KODENSHI D33 REEL SENSO
GP1S566V SHARP REEL SENSOR OF
DSAM 0121 DOOWON 2F 21P(BL BK)
THVV951BAA POSTECH DC 12 V 5 0
THVV951BAA POSTECH DC 12 V 5 0
THVV951BAA POSTECH DC 12 V 5 0
THVV951BAA POSTECH DC 12 V 5 0
THVV951BAA POSTECH DC 12 V 5 0
TADC M401D(GKI,LGIT) LG INOTEK
HC 49S BUBANG 10MHZ +/ 30 PPM
HC 49S KEUMSEOK 10 0000MHZ 30P
CFS 308 CITIZEN 32.768KHZ +/
C 001R SEIKO EPSON 32.768 KHZ
49U BUBANG 18432000HZ 30PPM 16
6-9
