Sony BVM-D32E1WA Maintenance Manual page 139

Ref.No. Part No. Description
Q073 8-729-027-54 TRANSISTOR DTC124XKA-T146
Q074 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q075 8-729-027-54 TRANSISTOR DTC124XKA-T146
Q121 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q122 8-729-027-54 TRANSISTOR DTC124XKA-T146
Q301 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q302 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q303 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q304 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q401 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q402 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q403 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q404 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q501 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q502 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q503 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q504 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q601 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q602 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q603 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q606 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q701 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q702 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q703 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q706 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q801 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q802 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q803 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q806 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q901 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q902 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q903 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q906 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1001 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1101 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1102 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1103 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q1111 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1112 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1113 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1114 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q1115 8-729-051-80 TRANSISTOR 2SJ182STL
Q1211 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1212 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1213 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q1214 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q1215 8-729-051-80 TRANSISTOR 2SJ182STL
<RESISTOR>
R001 1-216-025-91 RES-CHIP
R002 1-216-025-91 RES-CHIP
R003 1-216-025-91 RES-CHIP
R005 1-216-083-00 RES-CHIP
R006 1-216-025-91 RES-CHIP
R007 1-216-025-91 RES-CHIP
R008 1-216-025-91 RES-CHIP
R009 1-216-025-91 RES-CHIP
R010 1-216-025-91 RES-CHIP
R011 1-216-025-91 RES-CHIP
R012 1-216-097-91 RES-CHIP
R013 1-216-097-91 RES-CHIP
R014 1-216-295-91 SHORT
R015 1-216-073-00 RES-CHIP
R016 1-216-097-91 RES-CHIP
BVM-D32E1WA/D32E1WE/D32E1WU
Remark
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
27K 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
0
10K 5% 1/10W
100K 5% 1/10W
Ref.No. Part No. Description
R017 1-216-097-91 RES-CHIP
R018 1-216-097-91 RES-CHIP
R019 1-216-073-00 RES-CHIP
R020 1-216-073-00 RES-CHIP
R021 1-216-097-91 RES-CHIP
R022 1-216-025-91 RES-CHIP
R023 1-216-025-91 RES-CHIP
R024 1-216-025-91 RES-CHIP
R025 1-216-025-91 RES-CHIP
R071 1-216-677-11 METAL CHIP
R072 1-216-651-11 METAL CHIP
R073 1-216-651-11 METAL CHIP
R074 1-216-025-91 RES-CHIP
R075 1-216-065-91 RES-CHIP
R076 1-216-097-91 RES-CHIP
R077 1-216-057-00 RES-CHIP
R078 1-216-097-91 RES-CHIP
R080 1-216-295-91 SHORT
R081 1-216-097-91 RES-CHIP
R103 1-216-067-00 RES-CHIP
R106 1-216-017-91 RES-CHIP
R111 1-216-049-91 RES-CHIP
R112 1-216-049-91 RES-CHIP
R121 1-216-001-00 RES-CHIP
R122 1-216-001-00 RES-CHIP
R123 1-216-041-00 RES-CHIP
R124 1-216-041-00 RES-CHIP
R125 1-216-663-11 METAL CHIP
R126 1-216-663-11 METAL CHIP
R127 1-216-675-91 METAL CHIP
R128 1-216-681-11 METAL CHIP
R129 1-216-129-00 RES-CHIP
R130 1-216-675-91 METAL CHIP
R131 1-216-121-91 RES-CHIP
R132 1-216-033-00 RES-CHIP
R133 1-216-025-91 RES-CHIP
R134 1-216-025-91 RES-CHIP
R141 1-216-049-91 RES-CHIP
R151 1-216-097-91 RES-CHIP
R152 1-216-097-91 RES-CHIP
R153 1-216-097-91 RES-CHIP
R154 1-216-097-91 RES-CHIP
R155 1-216-097-91 RES-CHIP
R156 1-216-097-91 RES-CHIP
R157 1-216-097-91 RES-CHIP
R158 1-216-097-91 RES-CHIP
R159 1-216-017-91 RES-CHIP
R160 1-216-017-91 RES-CHIP
R161 1-216-017-91 RES-CHIP
R162 1-216-017-91 RES-CHIP
R171 1-216-663-11 METAL CHIP
R172 1-216-655-11 METAL CHIP
R173 1-216-651-11 METAL CHIP
R174 1-216-634-11 METAL CHIP
R175 1-216-634-11 METAL CHIP
R176 1-216-634-11 METAL CHIP
R177 1-216-663-11 METAL CHIP
R178 1-216-649-11 METAL CHIP
R201 1-216-049-91 RES-CHIP
R205 1-216-017-91 RES-CHIP
R221 1-216-651-11 METAL CHIP
R251 1-216-097-91 RES-CHIP
R252 1-216-097-91 RES-CHIP
R253 1-216-097-91 RES-CHIP
R254 1-216-097-91 RES-CHIP
BUF2
Remark
100K 5% 1/10W
100K 5% 1/10W
10K 5% 1/10W
10K 5% 1/10W
100K 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
100 5% 1/10W
12K 0.5% 1/10W
1K 0.5% 1/10W
1K 0.5% 1/10W
100 5% 1/10W
4.7K 5% 1/10W
100K 5% 1/10W
2.2K 5% 1/10W
100K 5% 1/10W
0
100K 5% 1/10W
5.6K 5% 1/10W
47 5% 1/10W
1K 5% 1/10W
1K 5% 1/10W
10 5% 1/10W
10 5% 1/10W
470 5% 1/10W
470 5% 1/10W
3.3K 0.5% 1/10W
3.3K 0.5% 1/10W
10K 0.5% 1/10W
18K 0.5% 1/10W
2.2M 5% 1/10W
10K 0.5% 1/10W
1M 5% 1/10W
220 5% 1/10W
100 5% 1/10W
100 5% 1/10W
1K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
47 5% 1/10W
3.3K 0.5% 1/10W
1.5K 0.5% 1/10W
1K 0.5% 1/10W
200 0.5% 1/10W
200 0.5% 1/10W
200 0.5% 1/10W
3.3K 0.5% 1/10W
820 0.5% 1/10W
1K 5% 1/10W
47 5% 1/10W
1K 0.5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
100K 5% 1/10W
9-23
