Using the Oracle System Assistant User Interface

2. Select whether you want to reboot or power off the system.
Oracle System Assistant exits. The system reboots or powers off if you selected one of those
options.

Using the Oracle System Assistant User Interface

The Oracle System Assistant user interface (UI) is divided into three sections, the left side Task
pane, the center Main pane, and the Platform Documentation, Help, and Exit pane, which is
located at the bottom of the UI.

Task and Main Pane

Oracle System Assistant is organized by tasks. The eight task buttons are located on the left side
of the interface in the Task pane.
152 Oracle X4 Series Servers Administration Guide • April 2016
