Prepare for Setup

Connect the Power Supply

Risk of electric shock due to incorrect connection.
➢ Ensure that the power receptacles intended for the
➢ Ensure that the power receptacles intended for the
Incorrect laying of the connection cables can cause tripping.
Fractures, contusions and bruises can be the result.
➢ Place the connecting cables so that nobody can trip over
To connect the power supplies, proceed as follows:
➢ Make sure that the main switch of the scanner is switched off (0
position).
➢ Use only the AC adapters and power cords supplied.
➢ Ensure the power cords are not damaged.
➢ Connect the connectors from the power supplies to the associated
24 Vdc connectors on the left of the scanner.
➢ If not already done, connect the supplied power cables to the
associated connectors on the power supplies.
➢ Connect the power plugs of the power supplies to power receptacles of
the correct voltage (100-240 Vac).

Establish the Network Connection

Incorrect laying of the connection cables can cause tripping.
Fractures, contusions and bruises can be the result.
➢ Place the connecting cables so that nobody can trip over
WARNING
connection are properly grounded.
connection of the scanner are properly fused.
them.
them.
CAUTION
CAUTION
Prepare for Setup
