Section Header Structure
Table A–6. Section Header Flags
A-8
Table A–6 lists the flags that can appear in the section header. The flags can
be combined. For example, if the flag's word is set to 024h, both
STYP_GROUP and STYP_TEXT are set.
Mnemonic Flag
STYP_REG 0000h
STYP_DSECT 0001h
STYP_NOLOAD 0002h
STYP_GROUP 0004h
STYP_PAD 0008h
STYP_COPY 0010h
STYP_TEXT 0020h
STYP_DATA 0040h
STYP_BSS 0080h
STYP_ALIGN 0700h
Note: The term loaded means that the raw data for this section appears in the object file.
The flags are in:
36 and 37
Description
Regular section (allocated, relocated, loaded)
Dummy section (relocated, not allocated, not loaded)
Noload section (allocated, relocated, not loaded)
Grouped section (formed from several input sections)
Padding section (loaded, not allocated, not relocated)
Copy section (relocated, loaded, but not allocated; relo-
cation and line-number entries are processed normally)
Section that contains executable code
Section that contains initialized data
Section that contains uninitialized data
Section that is aligned on a page boundary
Bytes For This COFF Format
COFF1
40 to 43 COFF2
