10.5.3 Creating a Map File of the ROMS Directive

Example 10–2. Map File Output From Example 10–1 Showing Memory Ranges
The map file (specified with the –map option) is advantageous when you use
the ROMS directive with multiple ranges. The map file shows each range, its
parameters, names of associated output files, and a list of contents (section
names and fill values) broken down by address. Following is a segment of the
map file resulting from the example in Example 10–1.
–––––––––––––––––––––––––––––––––––––––––––––––––––––
00004000..00005fff
–––––––––––––––––––––––––––––––––––––––––––––––––––––
OUTPUT FILES:
CONTENTS: 00004000..0000487f .text
00004880..00005b7f FILL = 00000000
00005b80..00005fff .data
–––––––––––––––––––––––––––––––––––––––––––––––––––––
00006000..00007fff
–––––––––––––––––––––––––––––––––––––––––––––––––––––
OUTPUT FILES:
CONTENTS: 00006000..0000633f .data
00006340..000066ff FILL = 000000ff
00006700..00007c7f .table
00007c80..00007fff FILL = 000000ff
Page=0 Width=8
rom4000.b0 [b0..b7]
rom4000.b1 [b8..b15]
Page=0 Width=8
rom6000.b0 [b0..b7]
rom6000.b1 [b8..b15]
Hex Conversion Utility Description
The ROMS Directive
"EPROM1"
"EPROM2"
10-21
