Please read the instruction carefully before use
16R Zoom Profile
Order code: ELUM021
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELUM021 and is the answer not in the manual?

Questions and answers

Related Manuals for Elumen8 ELUM021

Summary of Contents for Elumen8 ELUM021

  • Page 1 16R Zoom Profile Order code: ELUM021 User Manual Please read the instruction carefully before use...

  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions .................... 2 2. Technical Specifications .................... 3 3. Description ....................... 6 3.1 Description of the fixture ................. 6 3.2 Control Panel .................... 6 4. Gobos and Lamp ....................... 7 4.1 Gobos ....................... 7 4.2 Light Source ...................... 8 4.3 Changing the Lamp ................... 8 5. How To Set The Unit .................... 1 0 5.1 Main Functions .................... 1 0 5.2 Home Position Adjustment ................ 1 9 5.3 Error Information ................... 2 2 6. Control By Universal DMX Controller .............. 2 4 6.1 Connection ..................... 2 4 6.2 Address Setting .

  • Page 3: Safety Instructions

    1. Safety Instructions Please read the instructions carefully which includes important information about installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not accept liability for any resulting defects or problems. Unpack and check carefully that there is no transportation damage before using the unit. — The unit is for indoor use only. Use only in a dry location. — Only to be installed and operated by qualified operators. — DO NOT allow children to operate the fixture. — Use safety cables when hanging the unit. Handle the unit by its base only and not its head. — The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent — surfaces. Be sure that no ventilation slots are blocked, otherwise the unit will overheat. —...

  • Page 4: Technical Specifications

    The minimum distance between the light output lens and the illuminated surface must be more — than 12 meters. Disconnect mains power before fuse/lamp replacement or servicing. — Replace fuse/lamp only with the same type. — In the event of a serious operating problem, stop using the unit immediately. — Never turn the unit on and off in short intervals. — The housing, lenses, or the ultraviolet filter must be replaced if they are visibly damaged. — DO NOT open the unit as there are no user serviceable parts inside. — Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to — damage or malfunction. Please contact the nearest authorized technical assistance center if needed.

  • Page 5: Connection 2

    - Setting of DMX address and other functions without connection to mains power. - Battery for the LCD display charges automatically when the fixtures is connected to the mains power. - No need to change battery. Optical system - High efficiency optical system, delivering an extremely powerful output - High quality dichroic lenses Movement - Pan: 540° - Tilt: 270° - Pan/Tilt speed adjustable. - Automatic Pan/Tilt correction. - Easy calibration and maintenance with magnetic home positioning. - Pan/Tilt position lock for transporting protection. Dimmer/Shutter - Blackout, 0~100% smooth dimming, independent shutter and various strobe effects. Colour wheel - Colour wheel: 7 dichroic colours + open. - Rainbow effect in both directions. - Easy calibration and maintenance with magnetic home positioning. CMY - CMY speed adjustable. - Optional multiple preset colours and macros available. Gobo wheel - Gobo Wheel 1: 8 rotating, indexable, easily replaceable gobos + open. - Gobo Wheel 2: 14 metallic gobos + open.
  • Page 6 Focus - Focus effect. Iris - Motorized Zoom - Motorized linear zoom for smooth adjustment of the beam size and beam sharpness. Cool - Fan cooled Protocols - DMX 512 - Data input/output: 3/5 Pin XLR socket Weight - 23Kg Dimension - 435× 344×649mm...

  • Page 7: Description

    3. Description 3.1 Description of the fixture 1. Front panel 2. Base 3. Tilt lock 4. head 5. Arm 6. Pan lock 7. Handle 3.2 Control Panel Front view Rear view 1. Monitor (Batter Back-up display): LED: POWER...

  • Page 8: Gobos

    4. DMX input/output: For DMX 512 operation, use 3/5-pin XLR cables to link the units together 5. Power Cable: Connection to the incoming power supply. 6. Fuse (T 10A): Protects the unit from over voltage or short circuit 7. Power Switch: Turns the power On/Off 4. Gobo and Lamp 4.1 Gobos GOBO WHEEL 1 GOBO WHEEL 2 DANGER! Install the gobos with the unit switched off.

  • Page 9: Light Source

    4.2 Light Source PHILIPS MSD Platinum 16R 330W Because of its high internal pressure, there is a risk that the Discharge lamp can explode — during operation. The lamp emits intense UV radiation which is harmful to the eyes and skin. The high luminance of the arc can cause severe damage to the retina if you take a close look at the lamp when turned on.
  • Page 10 3. Lift the lamp out of its recess, disconnect the lamp and connect a new lamp that must be the same type as the old one and then place the new lamp into the lamp recess. Finally reinstall the head cover, fastening it securely before re-applying power. Warning: The installing direction of lamp:...

  • Page 11: How To Set The Unit

    5. How To Set The Unit 5.1 Main Function To select any of the given functions, press the MENU button up to where the required one is showing on the display. Select the function by pressing the ENTER button and the display will blink. Use the UP and DOWN buttons to change the mode. Once the required mode has been selected, press the ENTER button to setup. To go back to the functions without any changes press the MENU button again. Hold the MENU button for one second or wait for one minute to exit the menu mode. The main functions are shown overleaf:...

  • Page 13: Address Setting 2

    DMX Functions To select the DMX Functions, press the ENTER button to confirm, use the UP/DOWN buttons to select DMX Address, DMX Channel Mode or View DMX Value. DMX Address —DMX 512 address setting To select the DMX Address, press the ENTER button to confirm. Use the UP/DOWN buttons to adjust the address from 001 to 512, press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. DMX Channel Mode — channel mode To select the DMX Channel Mode, press the ENTER button to confirm. Use the UP/DOWN buttons to select Mode1 (23) channel mode, press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode.
  • Page 14 for one minute to exit menu mode. Fixture Setting To select the Fixture Setting, press the ENTER button to confirm, use the UP/DOWN buttons to select Pan Inverse, Tile Inverse, P/T Feedback, BL.O. P/T Moving, BL.O. Colour Change or BL.O. Gobo Change. Pan Inverse To select Pan Inverse, press the ENTER button to confirm. Use the UP/DOWN button to select No (normal) or Yes (pan inverse), press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. Tilt Inverse To select the Tilt Inverse, press the ENTER button to confirm. Use the UP/DOWN buttons to select No (normal) or Yes (tilt inverse), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. P/T Feedback To select the P/T Feedback, press the ENTER button to confirm. Use the UP/DOWN buttons to select No (Pan or tilt’s position will not feedback while out of step) or Yes (Feedback while pan/tilt out of step), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode.
  • Page 15 BL.O. Gobo Change — Blackout while change gobo To select the BL.O. Gobo Change, press the ENTER button to confirm. Use the UP/DOWN buttons to select No (normal while changing gobo) or Yes (blackout while changing gobo), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Lamp Setting To select the Fixture Setting, press the ENTER button to confirm, use the UP/DOWN buttons to select On/Off, State/Power on, Off via DMX, On if DMX on, Off if DMX off, Ignition Delay or Low Power Delay.. On/Off —Turn on/off the lamp To select the On/Off, press the ENTER button to confirm. Use the UP/DOWN buttons to select On (lamp on) or Off (lamp off), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. State/Power On — Lamp state while power on To select the State/Power On, press the ENTER button to confirm. Use the UP/DOWN buttons to select On (Lamp on while power on) or Off (Lamp off while power on), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Off via DMX — Turn off the unit via DMX controller To select the Off Via DMX, press the ENTER button to confirm, the present mode will blink on the display, use the UP/ DOWN buttons to select Yes (turn off the unit via DMX controller) or No (Don’t turn off the unit via DMX controller), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. (When you operate the unit via a DMX controller, set the value of the “special function” channel to “lamp off”.
  • Page 16 mode. (If the lamp is off via DMX signal, you can re-connect the DMX controller to make the lamp switch on). Off if DMX Signal is Lost — Lamp turns off when DMX signal is cut off. Select Off if DMX Signal is Lost, press the ENTER button to confirm, the present mode will blink on the display, use the UP/DOWN buttons to select Yes (Lamp turns off when DMX signal is cut off), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Ignition Delay — Delay time between power on and lamp on Select the Ignition Delay, press the ENTER button to confirm, the present mode will blink on the display, use the UP/DOWN buttons to adjust the delay time from 0S to 255S, press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode.
  • Page 17 Backlight Auto Off Select the Backlight Auto Off, press the ENTER button to confirm, the present mode will blink on the display, use the UP/DOWN buttons to select No (display always on) or Yes (display goes off one minute after exiting menu mode), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Backlight Intensity Select the Backlight Intensity, press the ENTER button to confirm, the present mode will blink on the display, use the UP/DOWN buttons to adjust backlight intensity from 1 (dark) to 10 (bright), press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Unit Temperature Select the Temperature Unit, press the ENTER button to confirm, the present mode will blink on the display, use the UP/DOWN buttons to select or , press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Fixture Test Enter the menu mode, select Fixture Test, press the ENTER button to confirm, use the UP/DOWN buttons to select Auto Test or Manual Test Auto Test Select Auto Test, press the ENTER button to confirm, the unit will run built-in programs to automatically test pan, tilt, shutter, colour, CMY, gobo, gobo rotation, prism, prism rotation, iris, frost, zoom, focus, dimmer and lamp on/off. Press the MENU button back to the last menu or exit the menu mode after auto test. Manual Test Select Manual Test, press the ENTER button to confirm, the current channel selection will show on the display, use the UP/DOWN buttons to select the channel options, press the ENTER button to confirm, then use the UP and DOWN button to adjust the value, press the ENTER button to...
  • Page 18 menu or leave the unit idle for one minute to exit menu mode. (All channel values will become 0 after exiting Manual Test menu) Fixture Information Enter menu mode, select Fixture Information, press the ENTER button to confirm, use the UP/DOWN buttons to select Fixture use time, Lamp On time or Firmware Version. Fixture use time Select Fixture use time, press the ENTER button to confirm, fixture use time will show on the display, press the MENU button to exit. Lamp On time Select Lamp On time, press the ENTER button to confirm, the lamp on time will show on the display, press the ENTER button to confirm, use the UP/DOWN buttons to select Exit or Reset Time, press the ENTER button to confirm. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode.
  • Page 19 Shutter — Reset Shutter Select Shutter, press the ENTER button to confirm, use the UP/DOWN buttons to select Yes (the unit will run a built-in program to reset the shutter to its home positions) or No, and press the ENTER button to store. Press the MENU button to exit. Colour/CMY — Reset Colour/CMY Select Colour/CMY, press the ENTER button to confirm, use the UP/DOWN buttons to select Yes (the unit will run a built-in program to reset colour and CMY to their home positions) or No, and press the ENTER button to store. Press the MENU button to exit. Gobo/Iris — Reset Gobo/Iris Select Gobo/Iris, press the ENTER button to confirm, use the UP/DOWN buttons to select Yes (the unit will run a built-in program to reset the Gobo wheel and Iris to their home positions) or No, press the ENTER button to store. Press the MENU button to exit. Focus/Zoom /Frost/Prism — Reset Focus/Zoom /Frost/Prism Select Focus/Zoom/Frost/Prism, press the ENTER button to confirm, use the UP/DOWN buttons to select Yes (the unit will run a built-in program to reset focus, zoom, frost and prism to their home positions) or No, and press the ENTER button to store. Press the MENU button to exit.

  • Page 20: Home Position Adjustment

    Fixture Maintenance Select Fixture Maintenance, press the ENTER button to confirm, use the UP/DOWN buttons to select Interval or Remain Time. Interval Select Interval, press the ENTER button to confirm, the interval time will show on the display. Press the MENU button to exit. Remain Time Select Remain Time, press the ENTER button to confirm, the remaining time will show on the display, press the ENTER button to confirm, use the UP/DOWN buttons to select Exit or Reset time, press the MENU button to exit. Factory Setting Select Factory Setting, press the ENTER button to confirm, the fixture will reset to factory settings and exit the menu mode. 5.2 Home Position Adjustment Press the MENU button into the menu mode, then press the ENTER button for 3 seconds into offset mode to adjust the home position. Select the function with the ENTER button. Use the UP/DOWN...
  • Page 21 Pan—pan home position adjustment Enter offset mode, Select Pan, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Tilt—Tilt home position adjustment Enter offset mode, Select Tilt, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Shutter—Shutter home position adjustment Enter offset mode, Select Shutter, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Colour—Colour home position adjustment Enter offset mode, Select Color, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button...
  • Page 22 to store. Press the MENU button to exit. Cyan—Cyan home position adjustment Enter offset mode, Select Cyan, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Magenta—Magenta home position adjustment Enter offset mode, Select Magenta, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Yellow—Yellow home position adjustment Enter offset mode, Select Yellow, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Gobo—Gobo home position adjustment Enter offset mode, Select Gobo, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. R-Gobo—Gobo rotation home position adjustment Enter offset mode, Select R-Gobo, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Gobo 2—Gobo 2 home position adjustment Enter offset mode, Select Gobo 2, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit.

  • Page 23: Error Information

    Prism—Prism home position adjustment Enter offset mode, Select Prism, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. R-Prism—Prism rotation home position adjustment Enter offset mode, Select R-Prism, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Zoom—Zoom home position adjustment Enter offset mode, Select Zoom, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Focus—Focus home position adjustment Enter offset mode, Select Focus, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Frost—Frost home position adjustment Enter offset mode, Select Frost, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN buttons to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. 5.3 Error Information Lamp Startup Fail It appears when there is no lamp or a faulty lamp. Temperature Sense Error It appears when temperature check board is faulty.
  • Page 24 Lamp Too Hot Low Power It appears when detected temperature is higher than 105 . the unit will run on a low power level. Maintenance Fixture It appears when the maintenance remaining time becomes 0S, please enter menu mode and reset the time. Lamp On Over 700 Hour It appears when the lamp has been on over 700 hours, please turn off the lamp. Memory Initial Fail It appears when the memory IC is damaged. CPU-B Error, CPU-C Error, CPU-D Error Pan Reset Error, Pan Encode Error, Tilt Reset Error, Tilt Encode Error, Shutter Reset Fail, Dimmer Reset Fail, Color Reset Fail, Cyan Reset Fail, Magenta Reset Fail, Yellow Reset Fail, Gobo1 Reset Fail, R-Gobo1 Reset Fail, Gobo2 Reset Fail, Iris Reset Fail, Effect Reset Fail, R-Effect Reset Fail, Frost Reset Fail, Flat Reset Fail, Focus Reset Fail, Zoom Reset Fail They may appear when turning on or resetting the unit.

  • Page 25: Control By Universal Dmx Controller

    6. Control By Universal DMX Controller 6.1 Connection ATTENTION Termination reduces signal errors and to avoid signal transmission problems and interference. It is always advisable to connect a DMX terminal (Resistance 120 ohm 1/4W between pin2 (DMX-) and pin3 (DMX+) of the last fixture). 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit. 2. Connect the units together in a “daisy chain” with a XLR cable from the output of the unit to the input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a very high-speed signal. Inadequate or damaged cables can easily corrupt the signal. The DMX output and input connectors are a pass-through type to maintain the DMX circuit even when one of the units power is disconnected.

  • Page 26: Address Setting

    3. Each unit needs to have a DMX address to receive the data by the controller. The address number is between 0-511 (usually 0 & 1 are equal to 1). 4. The end of the DMX 512 system should be terminated to reduce signal errors. 5. 3 3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+) 5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+), Pin4, Pin5 not used. 6.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button to enter the menu mode, select DMX Functions, press the ENTER button to confirm, use the UP/DOWN buttons to select DMX Address, press the ENTER button to confirm, the present address will blink the display, use the UP/DOWN buttons to adjust the address from 001 to 512, press the ENTER button to store. Press the MENU button back to the last menu or leave the unit idle for one minute to exit menu mode. Please refer to the following diagram to address your DMX512 channel for the first 4 units. Unit 1 Unit 2 Unit 3 Unit 4 Channel mode Address Address Address Address 23 channels 6.3 DMX 512 Configuration Please refer to the configurations overleaf to control the fixtures...
  • Page 27 23 Channels (Mode 1): CHANNEL VALUE FUNCTION PAN 000-255 0 ° " 540° 000-255 PAN FINE TILT 000-255 0 ° " 270° 000-255 TILT FINE P/T SPEED 000-255 Fast " Slow SPECIAL FUNCTION 000-069 No function 070-079 Enable blackout while pan/tilt moving 080-089 Disable blackout while pan/tilt moving 090-099 Enable blackout while color changing 100-109 Disable blackout while color changing 110-119 Enable blackout while gobo changing 120-129 Disable blackout while gobo changing 130-139 Lamp on 140-149 Pan/Tilt reset 150-159 Colour/CMY reset 160-169 Gobo/Iris reset 170-179 Shutter/Prism reset 180-189...
  • Page 28 194-255 Counter-Clockwise rotation, slow " fast CYAN 000-255 0 " 100% MAGENTA 000-255 0 " 100% YELLOW 000-255 0 " 100% PRESET COLOR 000-021 Open 022-042 Colour 1 043-063 Colour 2 064-085 Colour 3 086-106 Colour 4 107-127 Colour 5 128-148 Colour 6 149-170 Colour 7 171-191 Colour 8 192-212 Colour 9 213-233 Colour 10 234-255 Colour 11 CMY SPEED 000-255 Fast " Slow GOBO WHEEL 1 000-007 Open 008-014...
  • Page 29 190-193 Stop 194-255 Counter-clockwise rotation, slow " fast GOBO WHEEL 2 000-004 Open 005-009 Gobo 2-1 010-014 Gobo 2-2 015-018 Gobo 2-3 019-023 Gobo 2-4 024-028 Gobo 2-5 029-033 Gobo 2-6 034-037 Gobo 2-7 038-042 Gobo 2-8 043-047 Gobo 2-9 048-052 Gobo 2-10 053-056 Gobo 2-11 057-061 Gobo 2-12 062-066 Gobo 2-13 067-071 Gobo 2-14 072-075 Gobo 2-1 shaking 076-079 Gobo 2-2 shaking 080-083 Gobo 2-3 shaking 084-087 Gobo 2-4 shaking...

  • Page 30: Troubleshooting

    000-255 100% " 0 FOCUS 000-255 near" far FROST 000-255 0% " 100% IRIS 000-255 100% " 0 SHUTTER 000-007 Shutter Off 008-015 Open 016-131 Strobe, slow " fast 132-167 Slow open, fast close 168-203 Fast open, slow close 204-239 Slow open, slow close 240-247 Random strobe 248-255 Open DIMMER 000-255 0% " 100% 7. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the power connection and main fuse. B. Not responding to DMX controller 1. DMX LED should be on. If not, check DMX cables to see if they are connected correctly. 2.
  • Page 31 E. If The pan belt is broken 1. Turn off the mains power. 2. Loosen the screws (A)，open the cover (B). 3. Loosen the screws (C). 4. Unplug all the connection cables over the belt. 5. Replace the belt (D), put the belt around the axis gear and motor gear. 6. Re connect the cables over the belt. 7. Tighten all the screws. F. If The tilt belt is broken 1. Turn off the mains power. 2. Loosen all the screws (A) and open the right arm cover (B). 3. Loosen the screws (C) that fix the bridge. 4. Replace the belt (D). Please adjust the tension of the belt properly. Note: do not attach the belt too tightly as it is can easily snap. 5. Reverse the procedures from step 3 to 2.

  • Page 32: Maintenance And Cleaning

    8. Maintenance and Cleaning Maintenance: Ballast A. As the pictures shown above, please replace the cable or cable connectors immediately once they’ve turned yellow. B. Maintain the fixtures every two months and make sure that all the screws and terminals have been locked firmly. Negligence of maintenance will cause malfunction of the fixture and void the warranty.
  • Page 33 Cleaning: The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Ÿ Clean with soft cloth and use normal glass cleaning fluid to clean. Ÿ Always dry the parts carefully. Ÿ Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
  • Page 35 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008; EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008. & Harmonized Standard EN 60598-1:2008 + All:2009; EN 60598-2-17:1989 + A2:1991; EN 62471:2008; EN 62493: 2010 Safety of household and similar electrical appliances Part 1: General requirements...
