Phoenix Model A26 INVADER GP Instruction Manual page 8

Instruction Manual
2mm
approx. 13mm
2 x 10mm TP Screw
16
2x10mm
Cut away film only. here
Supplied with the servo
Pull out servo cord with string.
2x10mm
2x10mm
2x10mm
Aileron and Flap Servo
1.5mm
7
A26 INVADER
1.5mm
Warning!
Set all scerws securely. If they
come off during flight you will
lose control of your aircraft!
Pay close attention
Cut off shaded portion
Must be purchased
separately!
Assemble left and right
sides the same way
