MOUNTING THE COWL

1. Remove the muffler and needle valve assembly
from the engine. Slide the fiberglass cowl over
the engine.
2. Measure and mark the locations to be cut out
for engine head clearance, needle valve,
muffler. Remove the cowl and make these
cutouts using a rotary tool with a cutting disc
and a rotary sanding drum attachment.
3. Slide the cowl back into place. Align the front of
the cowl with the crankshaft of the engine. The
front of the cowl should be positioned so the
crankshaft is in the middle of the precut
opening. Hold the cowl firmly in place using
several pieces of masking tape.
3 x 10mm TP Screw
8
Trim the cowling so it will
match your engine
Plate of plywood
Cut off shaded portion
Assemble left and right
sides the same way
4. While holding the cowl firmly in position, drill
5. Using a 3mm drill bit, enlarge the holes in the
Enlarging the holes through the cowl will prevent
!
6. Slide the cowl back over the engine and secure it
7. Install the muffler. Connect the fuel and pressure
Washer
5mm
36
A26 INVADER
four 1,6mm pilot holes through both the cowl
and the side edges of the firewall.
cowling.
the fiberglass from splitting when the mounting
screws are installed.
in place using screws.
lines to the carburator, muffler and fuel filler
valve. Tighten the screws completely.
Apply epoxy glue
