Instruction Manual
INSTALLING THE RUDDER LINKAGES
3 x 12mm Screw
2
3mm Washer
2
3mm Nylon Nut
2
Aluminum ball
2
2
Locknut
2
3x30mm Connector
2
Set all screws securely. If they come off during
flight you will lose control of your aircraft!
Aluminum ball
Rudder Servo
3mm
Cable rod
20
A26 INVADER
3x12mm
3x12mm
3mm
3mm
3mm
Cut off excess.
Must be purchased separately!
Cut off shaded portion
Pay close attention
3mm
