Phoenix Model A26 INVADER GP Instruction Manual page 36

Instruction Manual
Assemble left and right
sides the same way
Adjust the throttle input (transmitter throttle stick), throttle trim movement and
the carburattor opening to the suitable position and screw in the 4x4mm set screw.
< Throttle Idling >
approx. 1mm
Throttle Servo
Carburetor
Ensure smooth, non-binding
movement when assembling
Apply threadlocker
(screw cement).
Throttle position of Tx.
< Throttle Hi >
35
A26 INVADER
4x4mm
< Throttle Stop >
Cut off shaded portion
Must be purchased
separately!
