A26 INVADER
GP/EP Size .46-.55 Scale 1:9 ¼ ARF
SPECIFICATION
- Wingspan: 2300mm (90.5 in)
- Length: 1664mm (65.5 in)
- Flying weight: 7000g-8000g
- Wing area: 61.4 dm2
- Wing loading: 105g/dm2
- Wing type: Naca airfoils
- Retract gear type: Air-retract With CNC
Suspension Metal Struts (included)
- Spinner size: Scale type (not included)
- Radio: 8 channel minimum (not included)
- Servo: 9 standard servo: 2 aileron; 2 flap;
1 elevator; 1 rudder; 2 throttle; 1 control
air valve (not included)
- Recommended receiver battery:
6.0V 2400/2600mAh NiMH (2) (not included)
- Servo mount: 21mm x 42 mm
- Propeller: suit with your engine
- Engine: 2 X .46-.55 Glow engine (two stroke)
(not included)
Instruction Manual
- Motor: brushless outrunner 850 W,
800 KV (not included)
- Experience level: Intermediate
- Plane type: Scale Warbird
- Gravity CG: 100 mm (3.9 in) Back from the
leading edge of the wing, at the fuselage
- Control throw Ailerons: Low: 9mm up/down,
10% expo; High: 12mm up/down, 10% expo
- Control throw Elevators: Low: 11mm up/down,
12% expo; High: 14mm up/down, 12% expo
- Control throw Rudder: Low: 20mm right/left,
15% expo; High: 35mm right/left, 15% expo
- Control throw Flaps: Mid: 10mm down;
Landing: 15mm down
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: 2 X RIMFIRE .32 (not included)
- Lipo cell: 2 X 4 cells / 4500 – 5500mAh (not included)
- Esc: 2 X 45A (not included)
GP
EP
version
version
