Helix 5 Device.fm Page 27 Tuesday, June 5, 2007 5:24 PM
3.
Press and hold SETUP until the red LED blinks
twice.
Enter 9 6 6 on the numeric keypad. The red
4.
LED blinks twice.
5.
Press CH+. The red LED blinks rapidly.
6.
Put the target (secondary) remote into
programming mode so that it sends its
information to the primary remote, as well as
receives information from the remote. The
remote then transfers the network and node
information to the new secondary remote.
Refer to the user manual for the secondary
remote for more information.
7.
The green LED blinks twice. You have
successfully transferred the information.
NOTE:
If the red LED emits one long, steady blink,
the information has not been successfully
transferred.
8.
Add nodes, groups, and scenes to the new
secondary remote as needed.
TRANSFERRING NETWORK INFORMATION TO A
SECONDARY REMOTE
You can add a secondary remote to your network, and
transfer your primary remote's network information to
it. To transfer network information to a secondary
remote, perform the following steps:
1.
Place the two remotes near each other.
2.
Press HOME.
Press and hold SETUP until the red LED blinks
3.
twice.
4.
Enter 9 6 6 on the numeric keypad. The red
LED blinks twice.
5.
Press CH-. The red LED blinks rapidly.
6.
Put the target (secondary) remote into
programming mode so that it sends its
information to the primary remote, as well as
receives information from the remote. The
remote then transfers the network and node
information to the new secondary remote.
Refer to the user manual for the secondary
remote for more information.
7.
The green LED blinks twice. You have
successfully transferred the information.
NOTE: If the red LED emits one long, steady blink, the
information has not been successfully transferred.
8.
Add nodes, groups, and scenes to the new
secondary remote as needed.
www.urcsupport.com
27
