Deleting All Learned Keys in a Specific Mode

NOTE: If more than 15 seconds pass between key
presses, the remote exits programming.
1. Press and hold SETUP until the last-selected
mode key blinks twice, then press 9 7 6.
2. Press a mode key twice (i.e., TV, DVD/VCR, SAT,
or AUX) to clear all the learned keys for that
mode. The LED blinks twice.
3. Repeat step 2 for another mode or press and
hold SETUP to exit programming.

PROGRAMMING CHANNEL CONTROL LOCK

By default, the remote control's channel-control
capabilities are locked to the cable converter. The
* are 1 through 0, CH+, CH-, and LAST. This
affected keys
will guarantee that you do not inadvertently change a
channel on your TV or VCR. However, you can de-
activate this feature to allow full access to these keys in
the TV and VCR modes.
*
NOTE: This feature does not affect the AMP mode.

Unlocking Channel Control

On the remote control, press SAT once; it will
1.
blink once. Press and hold SETUP until the SAT
key blinks twice.
2. Enter 9 7 3. The SAT key will blink twice.
3. Press CH- once. The SATSAT key will blink four
times.
Now the remote control will provide TV and VCR
channel-control capabilities while in the TV or VCR
mode.
