node to your home network. Please make sure
the remote is close to the node and try again.

Deleting a Node from the Network

To remove a node from your home network, you must
delete it from the network. To delete the node from your
network, perform the following steps:
1. Press HOME once.
2. Press and release DEL twice. The red LED
blinks rapidly.
3. Press the button on the node so that it sends
its information to the remote and receives
information from the remote.
4. The HOME LED blinks green twice.
NOTE: If the Home red LED emits one long, steady
blink, you have pressed an invalid key or the
node has not been successfully added the
node to your home network. Please make sure
the remote is close to the node and try again.

SETTING UP SCENES

A scene is a single node or group of nodes that can be
preset to turn to a previously specified setting
(brightness level). You can set up a maximum of 20
scenes, containing up to 64 nodes per scene.

Adding a Node to a Scene

Press HOME once.
1.
2. Press ADD once.
3. Press SCENE once.
4. Press a digit (1-9) for the scene you wish to
add the node to. The red LED blinks rapidly.
5. Press the button on the node so that it sends
its information to the remote and receives
information from the remote.
6. The green LED blinks twice, then the red LED
blinks rapidly. Adjust the brightness on the
node within 30 seconds.
NOTE: If the red LED emits one long, steady blink,
you have pressed an invalid key or the node
has not been successfully added the node to
your home network. Please make sure the
remote is close to the node and try again.
