Helix 5 Device.fm Page 17 Tuesday, June 5, 2007 5:24 PM
Locking Channel Control to SAT
1.
On the remote control, press SAT once; it will
blink once. Press and hold SETUP until the SAT
key blinks twice.
2.
Enter 9 7 3.The SAT key will blink twice.
3.
Press CH+ once. The SAT key will blink twice.
Now, regardless of what mode you select (except AMP),
the channel keys will only change channels on your cable
converter.
CHANGING VOLUME LOCK
Volume Lock allows you to control the volume through
the device identified as having your primary speaker(s),
regardless of which mode you are using. On the Helix Z-
wave 5-Device Remote Control with Learning, Global
Volume Lock is set to TV, so you can control TV volume
while in the VCR, DVD, TV or SAT mode. You can perform
Individual Volume Unlock on a selected device to set its
volume control for independent operation.
NOTE:
The audio mode's (AMP) volume controls are
active regardless of Volume Lock settings.
However, if you lock the volume controls to
the AMP mode, you will have control of the
audio device's volume in all other modes (i.e.,
VCR, DVD, TV, and SAT). This can be an advan-
tage if, for example, you always listen to home
entertainment devices through your receiver's
speakers.
Unlocking Volume Control for a Single Device
(Individual Volume Unlock)
1.
Assuming Global Volume Lock is active, select
a mode on the remote control that you want to
unlock (e.g., SAT) and press it once. Next,
press and hold SETUP until the device key
blinks twice.
2.
Enter 9 9 3. The last-selected device key will
blink twice.
www.urcsupport.com
17
