Atlas OCAP M1056.fm Page 1 Wednesday, April 30, 2008 2:52 PM
ATLAS OCAP 5-Device
Remote Control
Users Guide
PREPROGRAMMED FOR YOUR SET-TOP BOX

Advertisement

Table of Contents
loading

Related Manuals for Universal Electronics ATLAS OCAP 5

Summary of Contents for Universal Electronics ATLAS OCAP 5

  • Page 1 Atlas OCAP M1056.fm Page 1 Wednesday, April 30, 2008 2:52 PM ATLAS OCAP 5-Device Remote Control Users Guide PREPROGRAMMED FOR YOUR SET-TOP BOX...

  • Page 2: Table Of Contents

    Atlas OCAP M1056.fm Page 2 Wednesday, April 30, 2008 2:52 PM TABLE OF CONTENTS Introduction ..........4 Features and Functions .
  • Page 3 Atlas OCAP M1056.fm Page 3 Wednesday, April 30, 2008 2:52 PM Setup Codes for TV/VCR/DVD Combos ....51 Setup Codes for VCRs ....... 52 BACKLIGHTING TIPS Some Atlas OCAP models include backlighting for keypad illumination.

  • Page 4: Introduction

    Atlas OCAP M1056.fm Page 4 Wednesday, April 30, 2008 2:52 PM INTRODUCTION The Atlas OCAP 5-Device Remote Control by Universal Electronics is our latest generation universal remote control. Its sophisticated technology allows you to consolidate up to five of your original home entertainment remote controls into one easy-to-use product.

  • Page 5: Features And Functions

    Atlas OCAP M1056.fm Page 5 Wednesday, April 30, 2008 2:52 PM FEATURES AND FUNCTIONS Use the illustration below to locate features on the Atlas OCAP 5-Device Remote Control and then study the Key Charts (on the next three pages) to learn how they function.

  • Page 6: Key Charts

    Atlas OCAP M1056.fm Page 6 Wednesday, April 30, 2008 2:52 PM Key Charts Function Use SETUP for all programming sequences. Also use to turn backlighting on and off, if applicable. Press PWR once to turn on or off a home entertainment device.
  • Page 7 Atlas OCAP M1056.fm Page 7 Wednesday, April 30, 2008 2:52 PM Function Use VOL+ (or VOL-) to raise (or lower) the audio volume. Use FAV to cycle through your favorite channels stored in your cable converter. Use CH+ (or CH-) to select the next higher (or lower) channel.

  • Page 8: Device Table

    Please refer to the table below when performing the instructions in “Programming Device Control” on page 10 or “Setting Up a Combo Unit” on page 11. After programming, the Atlas OCAP 5-Device Remote Control will be able to control the following types of devices: Device Key...

  • Page 9: Installing Batteries

    Atlas OCAP M1056.fm Page 9 Wednesday, April 30, 2008 2:52 PM Device Key Controls these types of devices Television Cable Box (Converter) or Satellite Receiver INSTALLING BATTERIES ❶ ❷ ❸ On the back of the remote control, push the tab and lift off the battery cover. Locate the two (2) enclosed AA batteries.

  • Page 10: Programming Device Control

    Atlas OCAP M1056.fm Page 10 Wednesday, April 30, 2008 2:52 PM PROGRAMMING DEVICE CONTROL The Atlas OCAP 5-Device Remote Control is preprogrammed to operate the cable box (converter) provided by your cable system, an RCA TV, a Toshiba DVD player, an RCA VCR, and a Pioneer audio receiver.

  • Page 11: Setting Up A Combo Unit

    Atlas OCAP M1056.fm Page 11 Wednesday, April 30, 2008 2:52 PM Repeat steps 1 through 4 for each device you want the remote control to operate. For future reference, write down each working device code in the boxes on the following page. VCR Code Device Type:___________________ DVD Code...

  • Page 12: Searching For Your Code

    SEARCHING FOR YOUR CODE If your home entertainment device does not respond to the Atlas OCAP 5-Device Remote Control after trying all of the codes listed for your brand, or if your brand is not listed at all, try searching for your code.
  • Page 13 Atlas OCAP M1056.fm Page 13 Wednesday, April 30, 2008 2:52 PM Aim the remote control at the TV and press PWR once. Press and release the CH+ key continuously, then stop when the TV turns off. NOTE: In the search mode, the remote control will send IR codes from its library to the selected device, starting with the most popular code first.

  • Page 14: Checking The Codes

    Atlas OCAP M1056.fm Page 14 Wednesday, April 30, 2008 2:52 PM CHECKING THE CODES If you have set up the Atlas OCAP 5-Device Remote Control by searching for your device code (on the previous page), you may need to find out which four- digit code is operating your equipment.

  • Page 15: Unlocking Channel Control

    Atlas OCAP M1056.fm Page 15 Wednesday, April 30, 2008 2:52 PM Unlocking Channel Control On the remote control, press CBL once; it will blink once. Press and hold SETUP until the CBL key blinks twice. Enter 9 7 3. The CBL key will blink twice. Press CH- once.

  • Page 16: Unlocking Volume Control For A Single Device (Individual Volume Unlock)

    Atlas OCAP M1056.fm Page 16 Wednesday, April 30, 2008 2:52 PM NOTE: The audio mode’s (AUD) volume controls are active regardless of Volume Lock settings. However, if you lock the volume controls to the AUD mode, you will have control of the audio device’s volume in all other modes (i.e., VCR, DVD, TV, and CBL).

  • Page 17: Locking Volume Control To One Mode (Global Volume Lock)

    (e.g., TV) is controlled regardless of mode. PROGRAMMING CABLE ID LOCK The Atlas OCAP 5-Device Remote Control is locked at the factory to operate your cable provider’s set top box. However, if you have another brand or model of cable converter or satellite service that you would like to control, then you’ll need to perform the following steps...

  • Page 18: Programming Macro Keys

    Enter 9 8 2. The CBL key will blink twice, indicating ID Lock is again locked. PROGRAMMING MACRO KEYS The Atlas OCAP 5-Device Remote Control includes two macro keys (located directly below the MUTE and LAST keys). Macro keys allow you to set up key macros to activate certain keys in a specific order.

  • Page 19: Clearing A Macro Key

    18). If desired, repeat these to clear another Tune- In key. USING THE MASTER POWER KEY The Atlas OCAP 5-Device Remote Control has a unique feature that allows you to sequentially turn up to five of your home entertainment devices on or off with a single key press.

  • Page 20: Using The Master Power Key

    Atlas OCAP M1056.fm Page 20 Wednesday, April 30, 2008 2:52 PM Enter 9 9 5. The last-selected device key blinks twice. Press PWR once. For the first device you want in the power on sequence, press a device key (e.g., CBL) once. Then press PWR once.

  • Page 21: Re-Assigning Device Keys

    Press and hold SETUP until the CBL key blinks twice. RE-ASSIGNING DEVICE KEYS The Atlas OCAP 5-Device Remote Control can be set up to control a second device of an already-assigned type. For example, to have the unit control a TV, a Cable...

  • Page 22: Clearing Custom Programming

    ACTIVATING BACKLIGHTING (OPTIONAL) On some models of your Atlas OCAP 5-Device Remote Control, you can activate backlighting. Backlighting enables your remote’s keypad to remain lit for five seconds after you press any key. To enable backlighting...

  • Page 23: Troubleshooting

    Atlas OCAP M1056.fm Page 23 Wednesday, April 30, 2008 2:52 PM TROUBLESHOOTING PROBLEM: Device key does not blink when you press a key. SOLUTION: Replace the batteries with two (2) new AA batteries (see “Installing Batteries” on page 9). PROBLEM: Device key blinks when you press a key, but home entertainment device does not respond.

  • Page 24: Fcc Notice

    • For help via the Internet, visit us at: www.urcsupport.com ©Copyright 2006 by Universal Electronics Inc. No part of this publication may be reproduced, transmitted, transcribed, stored in any retrieval system, or translated to any language, in any form or by any means, electronic, mechanical, magnetic, optical, manual, or otherwise, without prior written permission of Universal Electronics Inc.

  • Page 25: Ímanufacturer's Codes

    Atlas OCAP M1056.fm Page 25 Wednesday, April 30, 2008 2:52 PM ÍMANUFACTURER’S CODES Setup Codes for Audio Amplifiers Adcom 0577, 1100 Bose 0674 Durabrand 1561 Elan 0647 0078 Harman/Kardon 0892 0331 Left Coast 0892 Lenoxx 1561 Luxman 0165 Marantz 0892, 0321 McIntosh 0251 Nakamichi...
  • Page 26 Atlas OCAP M1056.fm Page 26 Wednesday, April 30, 2008 2:52 PM Apex Digital 1257, 1430, 1774 Arcam 1120 Audiotronic 1189 Audiovox 1390, 1627 B & K 0701, 0820, 0840 0702 Bose 1229, 1629, 1841, 1933 Cambridge Soundworks 1370 Capetronic 0531 Carver 1189, 0189 Classic...
  • Page 27 Atlas OCAP M1056.fm Page 27 Wednesday, April 30, 2008 2:52 PM Optimus 1023, 0080, 0186, 0531, 0670, 1074 Oritron 1366, 1497 Panasonic 1308, 1518, 0309, 0367, 1288, 1316, 1548, 1633, 1763, 1764 Philips 1189, 1269, 0189, 0391, 1120, 1266 Pioneer 1023, 0014, 0080, 0150, 0244, 0531, 0630, 1384 Polaroid...

  • Page 28: Setup Codes For Audio Accessories

    Atlas OCAP M1056.fm Page 28 Wednesday, April 30, 2008 2:52 PM Setup Codes for Audio Accessories Accurian 1106 Altec Lansing 0607, 1056, 1485 Apple 1115, 1644 Cambridge Soundworks 1530 Creative 0872 D-Link 1522 1155 Integra 1789 iPort 1917 Marantz 1491 Motorola 1464 NaviPod...
  • Page 29 Atlas OCAP M1056.fm Page 29 Wednesday, April 30, 2008 2:52 PM Motorola 1376, 0476, 0810, 0276, 1187, 1254, 1106, 1540 Multitech 0883 Myrio 1602, 1822 Pace 1376, 1877, 0237, 0008 Panasonic 1376, 1877, 0000, 0107 Panther 0637 Paragon 0000 Philips 1305, 0317 Pioneer 1877, 0877, 0144, 0533...

  • Page 30: Setup Codes For Dvd Players

    Atlas OCAP M1056.fm Page 30 Wednesday, April 30, 2008 2:52 PM Setup Codes for Cable/DVR/PVR Combos Americast 0899 Amino 1822 Digeo 1187 General Instrument 0476, 0810 Jerrold 0476, 0810 Motorola 1376, 0810, 1187, 1106, 1540, 0476 Myrio 1822 Pace 1376,1877, 0237 Panasonic 1376, 1877 Pioneer...
  • Page 31 Atlas OCAP M1056.fm Page 31 Wednesday, April 30, 2008 2:52 PM Bel Canto Design 1571 Blaupunkt 0717 Blue Parade 0571 Broksonic 0695, 0868, 1419 Buffalo 1882 Cary Audio Design 1477 CAVS 1057 Centrios 1577 Cinea 0831 Cinego 1399 CineVision 0876, 0833, 0869 Citizen 1277 Coby...
  • Page 32 Atlas OCAP M1056.fm Page 32 Wednesday, April 30, 2008 2:52 PM 0699, 0769 Greenhill 0717 Harman/Kardon 0582, 0702 Hitachi 0573, 0664, 1247, 1919 Hiteker 0672 1348, 1472 Initial 0717, 1472 Innovative Technology 1542 Insignia 1268 Integra 0627 Jaton 1078 0702 Jensen 1016 1423...
  • Page 33 Atlas OCAP M1056.fm Page 33 Wednesday, April 30, 2008 2:52 PM 0741 Nakamichi 1222 0785 Nesa 0717, 1603 NeuNeo 1454 Next Base 0826 NexxTech 1402 Norcent 1003, 0872, 1107, 1265, 1457 Onkyo 0503, 0627, 0792 Oppo 1224, 1525 OptoMedia Electronics 0896 Oritron 0651...
  • Page 34 Atlas OCAP M1056.fm Page 34 Wednesday, April 30, 2008 2:52 PM Sharper Image 1117 Sherwood 0633, 0770, 1043, 1077, 1889 Shinsonic 0533, 0839 Sigma Designs 0674 Sonic Blue 0869, 1099 Sony 0533, 1533, 0864, 1033, 1431, 1432, 1433, 1548, 1892 Sound Mobile 1298 Sova...

  • Page 35: Setup Codes For Dvd Recorders

    Atlas OCAP M1056.fm Page 35 Wednesday, April 30, 2008 2:52 PM Setup Codes for DVD Recorders Accurian 1416 Apex Digital 1056 Aspire Digital 1168 Coby 1086 CyberHome 1129, 1502 Funai 0675, 1334 Gateway 1073, 1158 Go Video 0741, 1158, 1304, 1730 1348 1164, 1275 Kreisen...
  • Page 36 Atlas OCAP M1056.fm Page 36 Wednesday, April 30, 2008 2:52 PM Coolsat 1806 Crossdigital 1109 DirecTV 1377, 0392, 0566, 0639, 1639, 1142, 0247, 0749, 1749, 0724, 0819, 1856, 1076, 1108, 0099, 1109, 1392, 1414, 1442, 1443, 1444, 1609, 1640 Dish Network System 1505, 1005, 0775, 1170, 1775 Dishpro...

  • Page 37: Setup Codes For Tvs

    Atlas OCAP M1056.fm Page 37 Wednesday, April 30, 2008 2:52 PM Samsung 1377, 1276, 1108, 1109, 1442, 1609 Sanyo 1219 0856 Sony 0639, 1639, 1640 Star Choice 0869 Tivo 1142, 1442, 1443, 1444 Toshiba 0749, 1749, 0790, 1285 UltimateTV 1392, 1640 Ultrasat 1806 Uniden...
  • Page 38 Atlas OCAP M1056.fm Page 38 Wednesday, April 30, 2008 2:52 PM Advent 0761, 0783, 0815, 0817, 0842, 1933 Adventura 0046 Aiko 0092 Aiwa 0701 Akai 0812, 0702, 0030, 0098, 0672, 1207, 1903, 1935 Alaron 0179, 0183, 0216 Albatron 0700, 0843 Ambassador 0177 America Action...
  • Page 39 Atlas OCAP M1056.fm Page 39 Wednesday, April 30, 2008 2:52 PM Citizen 0060, 0030, 0092, 0039, 0046, 0056, 0186, 0280 Clairtone 0185 Clarion 0180 Commercial Solutions 1447, 0047 Concerto 0056 Contec 0180, 0157, 0158, 0185 Craig 0180, 0161 Crosley 0054 Crown 0180, 0039 Curtis Mathes...
  • Page 40 Atlas OCAP M1056.fm Page 40 Wednesday, April 30, 2008 2:52 PM FlexVision 0710 Fujitsu 0179, 0186, 0683, 0809, 0853 Funai 0180, 0171, 0179, 1271, 1963 Futuretech 0180 Gateway 1001, 1002, 1003, 1004, 1755, 1756 1447, 0047, 0051, 0451, 0178, 1347, 0747, 0282, 0279, 0251, 0174, 0138, 0135, 0055, 0029, 0027, 0021 Gibralter...
  • Page 41 Atlas OCAP M1056.fm Page 41 Wednesday, April 30, 2008 2:52 PM 0000 Jensen 0761, 0050, 0815, 0817, 1299, 1933 0053, 0036, 0069, 0160, 0169, 0182, 0731, 1253 Kamp 0216 Kawasho 0158, 0216, 0308 Kaypani 0052 0180 Kenwood 0030, 0019 0765, 0767, 1962 Kloss 0024, 0046, 0078 0106...
  • Page 42 Atlas OCAP M1056.fm Page 42 Wednesday, April 30, 2008 2:52 PM Minutz 0021 Mitsubishi 0093, 1250, 0150, 0178, 0014, 0019, 0098, 0155, 0331, 0358, 0836, 0868, 1550 Monivision 0700, 0843 Motorola 0093, 0055, 0835 Moxell 0835 0060, 0030, 0019, 0049, 0056, 0091, 0185, 0216 Multitech 0180, 0049, 0217...
  • Page 43 Atlas OCAP M1056.fm Page 43 Wednesday, April 30, 2008 2:52 PM Polaroid 0765, 0865, 1262, 1276, 1314, 1316, 1326, 1327, 1328, 1341, 1498, 1523, 1991, 1992 Portland 0092, 0019, 0039 Prima 0761, 0783, 0815, 0817, 1933 Princeton 0700, 0717 Prism 0051 Proscan 1447, 0047, 0747, 1347...
  • Page 44 Atlas OCAP M1056.fm Page 44 Wednesday, April 30, 2008 2:52 PM Sears 0047, 0054, 0154, 0156, 0178, 0171, 0015, 0056, 0146, 0148, 0149, 0159, 0168, 0179, 0281, 0747 Sharp 0093, 0039, 0153, 0157, 0165, 0220, 0281, 0386, 0398, 0491, 0688, 0689, 0818, 0851, 1602 Sheng Chia 0093 Sherwood...
  • Page 45 Atlas OCAP M1056.fm Page 45 Wednesday, April 30, 2008 2:52 PM Teknika 0054, 0180, 0150, 0060, 0092, 0016, 0019, 0039, 0056, 0175, 0179, 0186, 0312, 0322 Telefunken 0702, 0056, 0074 Tera 0031 Thomson 0209, 0210 0178, 0056, 0177 TNCi 0017 Toshiba 0154, 1256, 0156, 1265, 0060, 1945, 1935, 1704, 1656, 1635,...

  • Page 46: Setup Codes For Tvs (Dlp)

    Atlas OCAP M1056.fm Page 46 Wednesday, April 30, 2008 2:52 PM Zonda 0003 Setup Codes for TVs (DLP) Hewlett Packard 1494 1494 1265 Magnavox 1525 Mitsubishi 1250 Optoma 0887 Panasonic 1291 1447 Samsung 0812, 1060, 1312 0872 Toshiba 1265, 1306 Vizio 1499 Setup Codes for TVs (HDTV)
  • Page 47 Atlas OCAP M1056.fm Page 47 Wednesday, April 30, 2008 2:52 PM Byd:sign 1309, 1311 Cadia 1283 CyberHome 0794 Dell 1080, 1178, 1264 Emprex 1422, 1546 Envision 0813, 1365 FlexVision 0710 Funai 0171 Go Video 0886 Hannspree 1348, 1351 Hewlett Packard 1088 1088 Hyundai...

  • Page 48: Setup Codes For Tvs (Lcd)

    Atlas OCAP M1056.fm Page 48 Wednesday, April 30, 2008 2:52 PM Sceptre 0878, 1217, 1360, 1599 Sharp 0093, 0818, 1602 Sherwood 1399 Signet 1262 Sony 0810 Sova 1320 Soyo 1520 Superscan 0864 0587, 0870, 0871 Sylvania 0171, 1271 Symphonic 0171 Syntax 1144, 1240, 1331 Tatung...
  • Page 49 Atlas OCAP M1056.fm Page 49 Wednesday, April 30, 2008 2:52 PM Hitachi 1960 1990 Initial 1990 Insignia 1963, 2002 Jensen 1933 1962 1993 Magnavox 1963 Mintek 1990 Panasonic 1941 Polaroid 1991 Prima 1933 1948, 1958, 2002 Samsung 1903 Sansui 1935 Sova 1952 Sylvania...

  • Page 50: Setup Codes For Tv/Vcr Combos

    Atlas OCAP M1056.fm Page 50 Wednesday, April 30, 2008 2:52 PM Magnavox 1268 Mintek 1472 Panasonic 1490 Philips 0854, 1260 Polaroid 1480 Prima 1016 1022, 1193 Samsung 0899 Sansui 0695 Sova 1122 Sylvania 0675, 1268 Toshiba 0695 Setup Codes for TV/VCR Combos Controlled by the TV America Action 0180...
  • Page 51 Atlas OCAP M1056.fm Page 51 Wednesday, April 30, 2008 2:52 PM Mitsubishi 0807 Optimus 0162, 0454, 0593, 1162, 1262 Orion 0002, 0479, 1479 Panasonic 0162, 1035, 1162, 1262 Penney 0240, 1035, 1237 Quasar 0162, 1035, 1162 RadioShack 0000, 1037 0240, 0807, 1035, 1060 Samsung 1014 Sansui...
  • Page 52 Atlas OCAP M1056.fm Page 52 Wednesday, April 30, 2008 2:52 PM Controlled by the DVD Akai 0899 Broksonic 0868 Diamond Vision 1609 Emerson 0821 0821 Funai 1334 Magnavox 0821 Panasonic 1362, 1462 Polaroid 1482 1132 Sharp 0630 Superscan 0821 Sylvania 0821 Symphonic 0821...
  • Page 53 Atlas OCAP M1056.fm Page 53 Wednesday, April 30, 2008 2:52 PM Carver 0081 0072, 0278 Citizen 0037, 0278, 1278 Colt 0072 Craig 0037, 0047, 0240, 0072, 0271 Curtis Mathes 0060, 0035, 0162, 0041, 0760, 1035 Cybernex 0240, 0051 CyberPower 1972 Daewoo 0045, 0278, 0020, 0561, 0637, 1278...
  • Page 54 Atlas OCAP M1056.fm Page 54 Wednesday, April 30, 2008 2:52 PM Harwood 0072, 0068 Headquarter 0046 Hewlett Packard 1972 HI-Q 0047 Hitachi 0000, 0042, 0041, 0065, 0082, 0089, 0105, 0166 Howard Computers 1972 1972 Hughes Network Systems 0042, 0739 Humax 0739 Hush 1972...
  • Page 55 Atlas OCAP M1056.fm Page 55 Wednesday, April 30, 2008 2:52 PM Microsoft 1972 Mind 1972 Minolta 0042, 0105 Mitsubishi 0067, 0043, 0061, 0075, 0173, 0443, 0807 Motorola 0035, 0048 0240, 0000 Multitech 0000, 0072 0058 0104, 0067, 0041, 0038, 0040, 0050, 0082 Nikko 0037 Nikon...
  • Page 56 Atlas OCAP M1056.fm Page 56 Wednesday, April 30, 2008 2:52 PM Protec 0072 Pulsar 0039, 0051 Quarter 0046 Quartz 0046 Quasar 0035, 0162, 0077, 0454, 1035, 1162 RadioShack 0000, 1037 Radix 0037 Randex 0037 0060, 0240, 0042, 0149, 0058, 0065, 0077, 0105, 0106, 0202, 0760, 0761, 0807, 0880, 1035, 1060 Realistic...
  • Page 57 Atlas OCAP M1056.fm Page 57 Wednesday, April 30, 2008 2:52 PM Sylvania 0035, 0081, 0000, 0043, 0110, 0593, 1593, 1781 Symphonic 0000, 0593, 1593 Systemax 1972 Tagar Systems 1972 Tatung 0041 Teac 0000, 0041 Technics 0035, 0162 Teknika 0035, 0037, 0000, 0052 Thomas 0000 Tivo...
  • Page 58 Atlas OCAP M1056.fm Page 58 Wednesday, April 30, 2008 2:52 PM NOTES www.urcsupport.com/atlasocap...
  • Page 59 Atlas OCAP M1056.fm Page 59 Wednesday, April 30, 2008 2:52 PM NOTES www.urcsupport.com/atlasocap...
  • Page 60 Atlas OCAP M1056.fm Page 60 Wednesday, April 30, 2008 2:52 PM M1056 Revision 2.0...
