6. Installation

THIS PRODUCT REQUIRES A TWO PERSON LIFT TO MOUNT ON MOST DOORS
- use proper lifting techniques and equipment to suit the site.
6.1 Mounting The Drive Unit
a. Determine the centre of the door and mark this point on
6.1).
the wall above (Fig.
b. Raise the door to the open position.
c. Measure 50mm above the top of the door (at the doors
highest point) and mark this position
d. Mark the position of the wall bracket
wall above the door (Fig.
bracket is a minimum of 50mm above the top of the door
when in the open position.
e. Secure the wall bracket
appropriate fasteners (not supplied).
NOTE: The supporting structure where the bracket is
mounted, must be capable of supporting 2kN push / pull
force.
f. Measure 4080mm (+ /- 150mm) across the ceiling from the
6.2). Install perforated angle or similar
wall centre point (Fig.
(not supplied).
g. Turnover the drive unit
to release the vent (Fig.
h. Raise the opener into position using suitable equipment
for the height of the door.
NOTE:
The drive unit weighs over 25kg and therefore may
require 2 persons to mount into position.
i. Connect the rail to the wall bracket
22
opener to the perforated angle.
(Fig. 6.2).
holes on the
8
6.3). Check the bottom of the
in place with loxins or
8
and pull the ring located at
1
6.4).
and mount the
8
50mm minimum
4080mm minimum (+ / - 150mm)
Y
Track
Installation Instructions
Fig 6.1
Perforated angle
Door
Fig 6.2
8
Fig 6.3
Y
Fig 6.4
Axess Pro 1505
®
