Appendix
C - Control Board Adjustments
Door is driven to is automatically set to halfway during setting of the travel limits, but can be adjusted to suit.
iii. When Fire Input Is Configured As OPN :
will prevent the Door from closing.
6.13 Remote Code
The controller supports the Remote Code Set feature. This parameter can be used to disable the feature for security or
transmitter management reasons.
6.14 Activity Reports
This parameter enables activity report outputs. Contact Automatic Technology for more details.
6.15 Activity Report ID
This parameter sets the ID of the controller that is sent with the activity report. Contact Automatic Technology for more
details.
6.16 Vacation Mode
Vacation Mode blocks all but one designated remote control transmitter from activating the Axess
is activated by pressing a transmitter button with the VAC function assigned until the console displays that Vacation Mode
is enabled
(approx. 5 secs). When activated all the transmitter buttons will be ignored. To turn Vacation Mode off, press a transmitter
button with the VAC function assigned. Vacation Mode can also be turned on or off manually by editing the Vacation
Mode parameter. Vacation Mode can be turned on or off using this parameter.
6.17 Password Protection
The password feature enables all parameters and configuration settings to be protected unless a password is entered.
When this feature is turned on, the user is requested to enter the desired password to be used. The password protection
feature has a time-out that expires after 60 seconds of inactivity. Alternatively, the user may log out manually by pressing
exit when the main screen is displayed.
6.18 Transmitter Grouping
The transmitter store number display format can be changed to show a grouped format. When grouping is selected, instead
of displaying the store location as a number between 1 and 511, it will display as ##$ where ## is the group number and $
is a character a,b,c,d,e,f,g or h which indicates the group member.
6.19 Fault, Auto Reset
When selected, the controller will reset any fault automatically.
6.20 LED Low Power Mode
When LED low power mode is selected, the controller will turn the LED power off to save the power.
6.21 Console OSC Buttons
Console can be locked out by selecting console OSC buttons OFF.
6.22 AUX Output Operation
AUX output can be selected to be driven by:
i. Light Drive: Although the GDO10V3L2 drive unit has a light relay output, a light relay module can be connected on
the console between V+ and AUX OUT terminal which will turn the courtesy light on and off.
ii. Clock/Transmitter: By selecting this option, AUX output can be triggered by programming the clock timer or by the
transmitter.
iii. Open Status: Selecting this option will cause the AUX output to stay active as long as the Door stays open.
iv. Close Status: Selecting this option will cause the AUX output to stay active as long as the Door stays closed.
26 Axess Pro 1505
®
Activating the fire input will cause the Door to open. Holding the input
Installation Instructions
Pro 1505. The mode
®
