Appendix
A - Console Menu Structure
Parameter
Menu 6 - Operating Modes
Safety Close Mode
Safety Open Mode
Safety Beam Input Response Mode Sets the S.B response
mode. Options are OPEN and CLOSE cycles stop, Close
cycles stop or Close cycle reverse
SB REVERSE TIME
GPI INPUT MODE configure the GPI input. Options are OSC,
PED, SWP and DAY LIGHT SAVING
PED INPUT = SWIPE MODE Selects PED input functions as
pedestrian access swipe input
OPN INPUT N/C OPERATION
Selects operating polarity of OPN input
STP INPUT N/C OPERATION
Selects operating polarity of STP input
FIRE INPUT N/C OPERATION
Selects operating polarity of FIRE input
FIRE INPUT MODE configure the fire input. Options are OPN,
CLS and PED
REMOTE CODE ENABLED
Selects remote transmitter coding function
ACTIVITY REPORTS Select report to be output
ACTIVITY REPORT ID
Selects ID for controller, sent with activity report
VACATION MODE
Selects Vacation Mode - disables remote control
PASSWORD
Selects password protection for all changes
Transmitter Grouping
Fault Auto Reset
Selects Fault Auto Reset
LED Low Power Mode
Selects saving the power by turning LEDs Off
Console OSC Buttons
Selects to lock out the console buttons
AUX OUT O/P can be activated by either LIGHT DRIVE
,CLOCK/TXER/SB, OPEN or CLOSE status
Menu 7 - Time Clock
SET TIME / DATE
VIEW / EDIT PROGRAMS
SETTINGS
22 Axess Pro 1505
®
Installation Instructions
Min Max Default
Off On On
Off On Off
OPN & CLS stop CLS to
CLS to stop reverse
CLS to reverse
5 FULL FULL
OSC, OSC
PED,
DST
Off On Off
Off On N/O
Off On N/O
Off On N/O
OPN, OPN
CLS, PED
Off On On
Off 255 Off
0 65535 0
Off On Off
Off On Off
Off On Off
Off On Off
Off On Off
Off On On
LIGHT
DRIVE
Off On Off
Off On Off
Off On Off
Step Unit Menu Section
No.
6.1 13.1
6.2 Appendix C
6.3-5 Appendix C
1 Sec 6.6 Appendix C
6.7 Appendix C
6.8 Appendix C
6.9 Appendix C
6.10 Appendix C
6.11 Appendix C
6.12 Appendix C
6.13 Appendix C
1 6.14 Appendix C
1 6.15 Appendix C
6.16 Appendix C
6.17 Appendix C
6.18 Appendix C
6.19 Appendix C
6.20 Appendix C
6.21 Appendix C
6.22 Appendix C
7.1 14.1
7.2 14.2
7.3 14.3
