Overhead Garage Door Operator
Dominator Tempo & Syncro Instruction Manual
SYNCRO ATS-3
DOMINATOR TEMPO ATS-2AM
SECTIONAL DOOR OPENER
Doc # 160416_00
Part # 87406
Released 08/09/20
FOR RESIDENTIAL USE ONLY
SYNCRO ATS-3
DOMINATOR SYNCRO ATS-3AM
SMART SECTIONAL DOOR OPENER
Conforms to:
4008033
ANSI/CAN/UL325
Tested to comply
with Part 15 of the
FCC Rules

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dominator Tempo ATS-2AM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Automatic Technology Dominator Tempo ATS-2AM

Summary of Contents for Automatic Technology Dominator Tempo ATS-2AM

  • Page 1 4008033 ANSI/CAN/UL325 Tested to comply with Part 15 of the FCC Rules SYNCRO ATS-3 SYNCRO ATS-3 DOMINATOR TEMPO ATS-2AM DOMINATOR SYNCRO ATS-3AM SECTIONAL DOOR OPENER SMART SECTIONAL DOOR OPENER FOR RESIDENTIAL USE ONLY Doc # 160416_00 Part # 87406 Released 08/09/20...
  • Page 2 WARNING!: It is vital for the safety of persons to follow all instructions. Failure to comply with the installation instructions and the safety warnings may result in serious personal injury and/or property and remote control opener damage. Please save these instructions for future reference. ELECTROCUTION!: To reduce the risk of electric shock, this equipment has a grounding type plug that has a third (grounding) pin.

  • Page 3: Table Of Contents

    © Copyright 2019 CONTENTS Overhead Garage Door Operator 1. Safety Information 6.6 Coding Transmitters 2. System Specifications 6.6.1 Setting Remote Control Transmitter Codes 6.6.2 Install Wireless Wall Mounted Remote Transmitter 3. Operating controls 6.6.5 Remotely Coding Remote Control Transmitters 4. Kit Contents 6.6.3 Erasing All Remote Control Transmitter Codes 5.

  • Page 4: Safety Information

    1. Safety Information Please read these important safety rules WARNING! These safety alert symbols indicate personal • This operator should be installed in accordance with relevant US and safety property damage instruction exists. Canada Standards. READ THESE INSTRUCTIONS CAREFULLY. • To reduce the risk of injury to persons – Use this operator only with a sectional door.

  • Page 5: System Specifications

    © Copyright 2019 2. System Specifications Factory Default Settings Default Maximum Maximum motor run time 1 Minute Courtesy light time 180 secs Obstruction force margin 0.7 amp 1.5 amp Auto close time 0 seconds Technical Specifications Model SYNCRO ATS-3AMB SYNCRO ATS-3AM TEMPO ATS-2AMB TEMPO ATS-2AM Input Voltage...

  • Page 6: Operating Controls

    3. Operating controls Button Function 1. DOWN ARROW (Blue) Closes the door 2. DOWN ARROW LED (Blue) Illuminates when the door is closed and flashes when the door is obstructed on close or stopped. 3. STOP (Red) Stops the door 4.

  • Page 7: Kit Contents

    © Copyright 2019 4. Kit Contents Fig.4.1 1 x ATS drive unit 1 x Door bracket PLUS 1 x Wall mount transmitter kit 3 x Pin Snap SSP 8 ZNU 31080 16. 2 x Track Bracket 2 x Transmitters and batteries 10.

  • Page 8: Operator Safety & Security

    5. Operator Safety & Security 5.1 Manual Door Operation WARNING! When operating the manual release (while To disengage the operator from the door (preferably with the door in the the door is open) the door may fall rapidly due to weak or closed position), pull down on the string handle on an angle towards the door broken springs, or due to being improperly balanced.

  • Page 9: Installation Instructions

    © Copyright 2019 6. Installation Instructions IMPORTANT INSTALLATION INSTRUCTIONS WARNING! TO REDUCE THE RISK OF SEVERE INJURY OR DEATH: (1) READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. (2) INSTALL ONLY ON A PROPERLY OPERATING AND BALANCED GARAGE DOOR. AN IMPROPERLY BALANCED DOOR HAS THE POTENTIAL TO INFLICT SEVERE INJURY.

  • Page 10: C-Rail Assembly

    6.1 C-Rail Assembly 6.1.1 Installing the C-Rail ELECTROCUTION! This operator is a. Remove the Opener from the box. not equipped for permanent wiring. b. Locate and insert the shaft of drive unit into the C-Rail’s sprocket as shown in 6.1. Contact a qualified electrician to c.

  • Page 11: Securing The Powerhead Perforated Angle Or Equivalent

    © Copyright 2019 6.2 Mounting Operator for a Track Type Door 6.2.4 Securing the Powerhead Perforated Angle or equivalent a. Measure across the ceiling from the centre point 3155mm (+/- 50mm) to find a supporting beam. b. Create a perforated angle which best suits your site. Use a hack saw to cut the L shape metal strips.

  • Page 12: Safety Beam Installation

    6.3 Safety Beam Installation IMPORTANT NOTE: The Safety Beam must be installed and connected before the travel limits are set. 6.3.1 Safety Infra-Red Beam Kit (P/N 62047) A Safety Beam extends across the door opening. This Safety Beam is designed to detect an obstruction while the door is closing and to send a signal to the door operator to reverse or stop the door movement.

  • Page 13: Setting Speed And Limits

    © Copyright 2019 6.4 Setting Speed and Limits 6.4.1 Set the Limit Positions and adjust drive speed: The Limit Positions can vary due to site conditions, such as uneven ground. When setting the Close limit, ensure the position is when the Fig.6.4.1 door makes first contact with the ground.

  • Page 14: Safety Testing & Auto-Close

    6.5 Safety Testing & Auto-Close 6.5.1 Obstruction Detection Test Check the Safety Beam photoelectric sensor is operating after the installation. a. Place an obstruction (white vertical surface 6 in. high by 12 in. wide) in the center of the opening, perpendicular to the plane of the door when in the 6.5.1.

  • Page 15: Coding Transmitters

    © Copyright 2019 6.6 Coding Transmitters 6.6.1 Setting Remote Control Transmitter Codes BUTTON The opener can only operated from 4-button remote control transmitters that have been programmed into its memory. Up to TRANSMITTER 64 codes can be stored in the memory. FUNCTION a.

  • Page 16: Install Wireless Wall Mounted Remote Transmitter

    6.6 Coding Transmitters 6.6.2 Install Wireless Wall Mounted Remote Transmitter a. Turn the wall switch over and pull the tab to commission the battery. (Fig 6.6.2) b. Store the transmitter code as per instructions in Section 6.6.1. Test the transmitter button. c.

  • Page 17: Battery Backup

    © Copyright 2019 6.7 Battery Backup 6.7.1 Connecting the Battery Backup (Available with ATS-3AM model, optional for ATS-2AM) a. Remove the screw and open the cover to the batteries. (Fig.6.7.1) WARNING! After Step (c) the opener may become active (even when power is off). This is a result of a residual charge in the batteries.

  • Page 18: Auto-Ki Smart Phone Control

    6.9 Auto-Ki Smart Phone Control (ATS-3AMB Only) CLASS B DEVICE CAN ICES-3 (B)/NMB-3 (B) This equiment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 19: Operation Instructions

    © Copyright 2019 7. Operation Instructions IMPORTANT SAFETY INSTRUCTIONS WARNING! TO REDUCE THE RISK OF SEVERE INJURY OR DEATH: (1) READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. (2) NEVER LET CHILDREN OPERATE OR PLAY WITH DOOR CONTROLS. KEEP THE REMOTE CONTROL AWAY FROM CHILDREN.

  • Page 20: How To Use Your Operator

    7.1 How to Use Your Operator For maximum efficiency of your operator, your garage door must be in good operating condition. An annual service of your garage door by door professional is recommended. CAUTION: Activate the operator only when the door is Fig.7.1.1 in full view, free of obstructions and with the operator properly adjusted.

  • Page 21: User Operating Controls

    © Copyright 2019 7.2 User Operating Controls Button Function 1. DOWN ARROW (Blue) Closes the door 2. DOWN ARROW LED (Blue) Illuminates when the door is closed and flashes when the door is obstructed on close or stopped. 3. STOP (Red) Stops the door 4.

  • Page 22: Troubleshooting

    7.3. Troubleshooting Symptom Possible cause Remedy The opener does not work Garage door in poor condition e.g. springs Check the door’s operation from the transmitter may be broken The opener does not have power Plug a device of similar voltage (e.g. a hairdryer) into the power point and check that it is OK Replace the battery The battery in the transmitter is flat...

  • Page 23: Service / Warning Indicator

    © Copyright 2019 7.4. Service / Warning Indicator 7.4.1 Main Light = Service / Warning Indicator: Requirements for a service and user warnings are indicated after operation by the main light repeatable flashing OFF a number of times followed by a pause. The below table identifys the issues and remedies.

  • Page 24: Appendix

    9. Appendix A - Status Indication during Operating Mode. LEDs Light Status Description BLUE GREEN YELLOW PURPLE solid Open DOOR OPEN CLOSED LEDS flashing Open with Autoclose timer running flashing Opening / Obstructed on Open solid Closed flashing Closing / Obstructed on Close flashing flashing Stopped...

  • Page 25: B - Adjustment Mode Instructions

    © Copyright 2019 B - Adjustment Mode Instructions a. Press the MODE button repetively until the GEAR LED starts flashing b. Referring to the table below, select the desired parameter using the OPEN and CLOSE buttons and observing the number of flashes on the GEAR LED.

  • Page 26: E - Setting Limits Via Transmitter

    E - Setting limits via Transmitter Button 1 (inch Open) Button 2 (Set) a. Switch power on and the BLUE LED on the CLOSE button will start to flash to indicate that the opener is ready to set the Close travel limit b.

  • Page 27: F - Setting The Pet Mode Position

    © Copyright 2019 F - Setting the PET Mode position When activated, PET mode drives the door to a preset position from the close position, therefore allowing a pet or parcel to go under the door. a. Drive and stop the door at the desired PET mode open position by pressing the transmitter button coded for Open/Stop/Close operation.
