17. Accessories Installation

17.1 Fitting Courtesy Lights
A light relay module (optional) can be connected to the aux out on the console to control the courtesy light.
WARNING: A qualified electrician must perform the installation where 240V AC power is used.
Menu 4. Light Times
a. Press NEXT or PREV on the wall control unit to navigate to Menu 4 Light/Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the sub menu.
d. Press OPEN to increase or CLOSE to decrease the time.
e. Press SET to save the new time.
f. Press the STOP button two times to exit.
g. Test the light operation.

18. Specifications

Technical Specifications
Power supply
Motor type
Model
Motor Power
Track
Maximum Door Opening
Maximum Door Size / Area
Duty Cycle
Receiver type
Receiver code storage capacity
Receiver Sensitivity
Transmitter frequency
Coding type
Number of code combinations
Code generation
Controller fuse
Transmitter Battery
Real Time Clock Battery
NOTE:
a. If the Safety Beams are not installed then the controller will automatically go into "Safety Close" mode. A limited
number of features are available in this mode, please refer to menu 6.1 in Section 13.1.
18 Axess Pro 1505
®
Single Phase 240 Volts (Delta Connection)
4m Track
3.6m
25m
Installation Instructions
Single Phase
230Va.c. 50Hz
AX1505
0.373 KW
2
60%
UHF Multi-frequency FM Receiver
511 X 4 button Transmitter Codes
– 103 dB
UHF Multi-frequency FM Transmitter
Code hopping
Over 100 billion random codes
Non-linear encryption algorithm
10A slow blow
CR - 2032 (3 Volts)
CR -1220 (1.5 Volts)
6m Track
5.6m
25m
2
