1. Important Safety Instructions

The safety alert symbols below indicate a personal safety or property damage instruction
exists. READ THESE INSTRUCTIONS CAREFULLY.
This automatic Door opener is designed and tested to offer safe service provided it is installed
and operated in strict accordance with the following safety rules. Failure to comply with the
following instructions may result in death, serious personal injury or property damage.
WARNING!
ELECTROCUTION!
CAUTION:
Emergency access
Entrapment under
operating door
Installation
Security
Entanglement in
moving door
TWO PERSON LIFT:
4 Axess Pro 1505
®
• The Door may operate unexpectedly, therefore do not allow anything to stay in the path
of the door.
For Safety protection, a Safety Beam must be fitted with logic console. Failure to comply
•
will void the warranty and may result in serious personal injury and/or property damage .
• The drive must not be used with a Door incorporating a wicket door, unless the drive cannot
be operated with the wicket door open.
• The drive is intended to be installed at least 2.5m above the floor.
• DO NOT allow children to operate the opener. Any device that can operate the opener,
make sure it is out of reach of children and that the doorway is in full view at all times. Serious
personal injury and/or property damage can result from failure to follow this warning.
• When using auto close mode, a Safety (Photo Electric) Beam must be fitted correctly and
tested for operation at regular intervals. Extreme caution is recommended when using
auto close mode. All safety rules must be followed.
• Place opener in protected area so that it does not get wet.
• Do not spray with water .
• Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the opener.
• If the power supply cord is damaged, it must be replaced by an Automatic Technology
service agent or suitably qualified person.
• Electrical wiring must be compliance with the local building an electrical codes.
• If your facility has no pedestrian entrance door, an emergency access device should be
installed.
• DO NOT operate the opener unless the Door is in full view and free from objects such as
cars and children/people. Make sure that the Door has finished moving before entering or
leaving the premises.
• Do not allow children to play with Door controls or transmitters.
• Ensure the Door is in good working order by undertaking regular servicing.
For ADDITIONAL SAFETY protection we STRONGLY recommend the fitting of a Safety
•
(Photo Electric) Beam.
• Safety beams must be installed if the closing force at the bottom edge of the door exceeds
400N (40kg)
• Frequently examine the installation, in particular, springs and mountings for signs of wear,
damage or imbalance. DO NOT use if repair or adjustment is needed since a fault in the
installation or an incorrectly balanced Door may cause injury. DO NOT attempt to repair
the Door yourself as hardware is under extreme tension.
•
The Door must be well balanced and in good working order. Door springs, brackets and their
hardware are under extreme tension and can cause serious personal injury. Do not attempt
to adjust them. A faulty Door must be repaired by a industrial roller Door professional prior
to opener installation.
• Remove or disengage all Door locks and mechanisms prior to installation of the opener.
• Ensure no parts of the Door or installation extend over public paths or roads.
• After installation a full function test of the system and safety devices must be done.
• Make sure the Door is fully closed before leaving the driveway. .
• Keep hands and loose clothing clear of Door and opener at all times.
• This product requires a two person lift to mount on most doors. Use proper techniques and
equipment to raise the unit above the door to suit the site.
