Summary of Contents for Automatic Technology Axess Pro Series 3000
- Page 1 Axess® Pro Series 3000 Commercial Shutter Opener Featuring TrioCode ™ Technology Part # 92647 (Manual) V1.00 INSTALLATION INSTRUCTIONS | OWNERS COPY...
- Page 2 Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology (Australia) Pty Ltd commercial shutter opener.
-
Page 3: Table Of Contents
Axess® Pro Series 3000 Commercial Shutter Door Opener Important Safety Instructions Features Package Contents Controllers Input And Output Operating Controls Before Drive Unit Installation Installation EasyBeam™ Installation Programming The Opener Menu Structure Viewing And Editing Parameters Setting Limits Setting Limits: Via Transmitter Coding Transmitters Transmitter Editing Transmitter Management... -
Page 4: Important Safety Instructions
Important Safety Instructions WARNING: It is vital for the safety of people who install, maintain or operate the door to follow all instructions. Failure to comply with the following Safety instructions may result in serious personal injury and/or property damage. For Safety protection, a Photo Electric Beam must be fi... - Page 5 Important Safety Instructions Please read this installation instruction manual before attempting to install, maintain or use the opener. Failure to comply with the instructions may result in serious injury and/or property damage. Connect the power supply cord to properly earthed mains. Electrical wiring must be compliance with your local building and electrical codes.
-
Page 6: Features
Features Thank you for purchasing the Axess® Pro Series 3000 Commercial Shutter Opener. This opener is designed to suit commercial heavy duty Shutter doors. The components and materials used in this opener are of the latest technology and highest quality. Listed below are some of the many features. - Page 7 Security Code Store The opener uses state of the art technology in storing your selected transmitter codes. Up to 511 different transmitters can be stored in the opener’s memory with the facility to assign a 11 character name to each transmitter. Remote Limits Positioning During installation, a hand held transmitter can be used when setting the door travel limits.
-
Page 8: Package Contents
Package Contents Axess 3110v1 Power Drive Unit Timing Assembly Wall Control Unit Network Cable Output Drive Shaft Assembly Chain 10B (0.625”) Sprocket 14x0.625 assembly Mounting Flange Ax30 Fasterner Pack TrioCode™ Keyring Transmitters Installation Manual EasyBeam™ with wires and brackets Network Cable Wall Control Unit Timing assembly Transmitters... - Page 9 Controller Input And Outputs fi g Motor identifi cation harness connector cluch interlock microswitch connector Serial Interface Connector Position Sensor Connector 10 Amps Slow Blow FuseStandby Battery Owner Installation Instructions Axess® Pro Series 3000...
-
Page 10: Operating Controls
Operating Controls fi g Terminal Block ( From Left To Right ) Programmer PG-3 Input V+ Three Wire PE Beams “ + “ Supply Console Previous Button IN3 Three Wire PE Beams Trigger Input Liquid Crystal Display V- Common For Two Wire EasyBeam™ and Three Console Next Button Wire PE Beams Console Open Button... -
Page 11: Before Drive Unit Installation
Before Drive Unit Installation The Axess® Pro Series 3100 Roller Shutter Door Opener is designed to operate most commercial heavy duty roller shutter doors. The door must be in good working condition and travel freely in the guides. fi g Step 1 - Initial Check Before commencing installation check the following: The door moves freely for the full travel in both... -
Page 12: Installation
Installation Step 3 - Mounting The Drive Unit Open the shutter about one metre from the fl oor. Raise the drive unit to the required height by using a suitable lifter or use chain block connected to a secure beam above the door axle. Position opener and secure with four M12x30 screws. -
Page 13: Easybeam™ Installation
Repeat steps a and b to assemble the EasyBeam™ receiver. Locate the Photo Electric (PE) Beams in a strategic location in the doorway. Automatic Technology recommend that the sensor is placed 100mm above the fl oor level and as close as possible to the door opening. -
Page 14: Programming The Opener
Programming The Opener Menu structure NOTE: System will automatically return to the main screen NOTES after 30 secs if a menu screen is displayed and no buttons 1. Press PREV/NEXT buttons move to Left/Right. are pressed. 2. Press OPEN/CLOSE buttons to change setting. 3. -
Page 15: Viewing And Editing Parameters
Viewing and Editing Parameters This section illustrates how to locate, view and View Mode (No cursor) adjust parameters. Parameter name Parameter number in sub menu Locating parameters 2: 100% O/L Time Refer to MENU STRUCTURE on Page 15 or the preceding Parameter (sec) section for CONTROL BOARD ADJUSTMENTS. -
Page 16: Setting Limits
Setting Limits Step 6.1 - Setting Travel Limits To Desired CLOSE Limit, Secure the engage/disengage handle and string with the accessory supplied in such a manner so that the string is away from the moving parts. Turn on the power to the opener. The controller will fi... -
Page 17: Setting Limits: Via Transmitter
Setting Limits: Via Transmitter Axess® Pro 3000 series shutter opener has the alternate ability to set travel limits using the transmitter, allowing free movement around the installation site to better MENU 1 assess the desired limit positions. In order to use a Code Transmitter transmitter, it must fi... -
Page 18: Coding Transmitters
Coding Transmitter Axess® pro series 3000 shutter door opener can store ID/SN display indicator I.D label/Serial number up to fi ve hundred and eleven (511) transmitters in its memory. Each transmitter can be allocated an alpha- numeric ID label up to eleven (11) characters in length Store number fi... -
Page 19: Transmitter Editing
Editing Transmitter Settings MENU 1 Code Transmitter Display Transmitter Record Using one of the methods below, display the required fi g transmitters details. PR E S S Navigating To “Edit Transmitter” Menu 1. Press NEXT to navigate to Menu 1 (Fig. - Page 20 Transmitter Editing (cont.) Editing The Store Location 14 I [No Name] This feature is only available when coding the fi rst OSC PED LGT VAC button of a new transmitter. 1. Press NEXT or PREV to move the cursor over Store fi...
-
Page 21: Transmitter Management
Transmitter Management Axess® Pro 3000 series shutter opener provides a MENU 1 transmitter listing facility which enables the user to fi nd Code Transmitter a transmitter location within the memory. Once located a stored transmitter can be replaced, deleted, edited, PRESS fi... - Page 22 Transmitter Management Code Operation (location used) If the code operation is selected for a location that MENU 1.2 already contains a transmitter, then the BASIC CODE Delete TRANSMITTER PROCEDURE will be initiated and the new transmitter will replace the existing one. Note that the button functions and name of the existing fi...
-
Page 23: Remotely Coding Transmitters
Remotely Coding Transmitters If a transmitter is already coded into the opener, additional transmitters can be coded without being in direct contact with the opener’s control panel. PRESS Existing NOTE: Only the function of the existing transmitter transmitter button can be assigned to new transmitter. Please fi... -
Page 24: Setting Pedestrian Position
Setting Pedestrian Position Pedestrian Access Position After completing the limit setup procedure the MENU 10.3 Pedestrian Access position is automatically set to Set Pedestrian a position which is approximately in the middle of the door travel. The position can be manually set by following the SETTING PEDESTRIAN POSITION fi... -
Page 25: Control Board Adjustments
Details about the four Auto-Close modes follow. Pedestrian access Auto-Close Automatic Technology strongly recommend using a PE This mode is selected by entering a non-zero Beam for added safety. -
Page 26: Light Times
Parameter Default Step Unit Menu No. STD AUTO-CLOSE TIME 300.0 Sets and enables the standard Auto-Close time. P.E AUTO-CLOSE TIME Sets and enables the P.E 60.0 triggered Auto-Close time. PEDESTRIAN AUTO-CLOSE TIME Sets and 60.0 enables the Pedestrian Auto-Close time. P.E PEDESTRIAN AUTO-CLOSE TIME Sets and 60.0 enables the PE Pedestrian Auto-Close time. -
Page 27: Motor Settings
Menu 5. Motor Settings Motor Speed The speed of the motors run at is controlled by the OPEN AND CLOSE SPEED FREQUENCY parameter. The default value is the maximum recommended for normal operation. If however the door moves too quickly or slowly for a particular installation, the frequency can be reduced or increased to make the motors run slower or faster. - Page 28 Control Board Adjustments If the door is moving, the activation of the GPI input or by a transmitter button with the OSC function assigned will cause the door to stop. The next trigger will move the door in the opposite direction to the last travelled. When GPI Input Is Confi...
- Page 29 This parameter enables activity report outputs. Contact Automatic Technology for more details. 6.14 Activity Report ID This parameter sets the ID of the controller that is sent with the activity report. Contact Automatic Technology for more details. 6.15 Vacation Mode Vacation Mode blocks all but one designated remote control transmitter from activating the Axess®...
- Page 30 Control Board Adjustments Parameter Default Step Unit Menu Safety Close Mode PE Beams INPUT RESPONSE MODE Sets the P.E OPN & CLS stop CLS to response mode. Options are OPEN and CLOSE CLS to stop reverse cycles stop, Close cycles stop or Close cycle reverse CLS to reverse PE REVERSE TIME FULL...
-
Page 31: Time Clock
Time Clock The opener provides a programmable time clock which MENU 8.1 can be used to control the Axess® Pro Series 3000 Set Time/Date shutter opener on a timed basis at various times of the week. This section details the time clock operation and fi... - Page 32 Time Clock The selectable functions available are: When GPI Input Is Confi gured As PED: The activation of the GPI input or by pressing a transmitter RX = Off button with PED function assigned will open the door From the time when the program with RX = OFF is partially to allow pedestrian access but prevent vehicle activated, all the transmitters will be disabled.
-
Page 33: Diagnostic Tools
Diagnostic Tools The controller provides several diagnostic tools from MENU 9 within the Diagnostics Menu (Menu 8). This section Diagnostics details the function of each tool and its use. fi g Navigating To Diagnostics Menu 1. Press PREV to navigate to Menu 8 (Fig. - Page 34 Diagnostic Tools Menu 8.5 Service Counter Service Counter The opener provides a periodic service counter which (Cycles) 60000 can be set to expire after a number of drive cycles. When expired, the opener will beep three times at fi g the beginning of each drive cycle and a message will be displayed on the MAIN SCREEN (Fig.
-
Page 35: Memory Tools
Memory Tools Menu 9.0 Memory Tools The Memory Tools accessed from within Menu 9 are used to clear the transmitters codes from the openers memory and clear the controller’s memory. Once selected, the PREV or NEXT buttons can be used to view the Memory Tool options. -
Page 36: Specifi Cations
Specifi cations Technical Specifi cations Power supply 230V - 240Va.c. 50Hz Motor power 750 Watts Motor type Three Phase 240 Volts (Delta Connection) Maximum door opening: Height: 6000mm Width: 6000mm Weight: 550kg Opener Limits Travel 21 turns of output shaft Duty Cycle Receiver type UHF Multi-frequency FM Receiver... -
Page 37: Troubleshooting
Troubleshooting Symptom Possible cause Remedy Blank display screen. Mains power not switched on. Switch on mains power. Network cable not connected. Connect the network cable. Controls cover is lose or missing. Install the controls cover. Wall control unit displays “ Drive Hand chain is not freely hanging. -
Page 38: Maintenance
Maintenance Yearly The shutter door should be tested regularly to Automatic Technology suggests you contact your shutter ensure it is in good condition. A poorly maintained door professional to perform an annual door service. door could cause fatal or serious injuries or serious damage to property. - Page 39 Spare Parts Owner Installation Instructions Axess® Pro Series 3000...
-
Page 40: Warranty
Trade Practices Act 1974 (Cwth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants: (a) roll up door opener drive units for twenty four (24) months or 5000 cycles, whichever occurs fi rst; and (b) all components and accessories for twelve (12) months, from the date of purchase (specifi... - Page 41 © Dec 2010 Automatic Technology (Australia) Pty Ltd. All rights reserved. TrioCode™ , Toro™ ,EasyBeam™ and SmartSolar are trademarks of Automatic Technology (Australia) Pty Ltd. No part of this document may be reproduced without prior permission. In an ongoing commitment to product quality we reserve the right to change specifi cation without notice.
