7 — DIAGNOSTICS & TROUBLESHOOTING
34
Type 0 Fault Codes
When Fault Code Type parameter is set to 0, the status LED uses a 2-digit
code. For example, code "1,4"—undervoltage—appears as:
¤ ¤ ¤ ¤ ¤
( 1 , 4 )
The Type 0 fault codes are listed in Table 2-0.
Table 2-0 STATUS LED FAULT CODES, TYPE 0
TYPE 0 LED CODES
LED off
solid on
1,1
¤ ¤
1,2
¤ ¤¤
1,3
¤ ¤¤¤
1,4
¤ ¤¤¤¤
1,5
¤ ¤¤¤¤¤
2,1
¤¤ ¤
2,2
¤¤ ¤¤
2,3
¤¤ ¤¤¤
2,4
¤¤ ¤¤¤¤
2,5
¤¤ ¤¤¤¤¤
3,1
¤¤¤ ¤
3,2
¤¤¤ ¤¤
3,3
¤¤¤ ¤¤¤
3,4
¤¤¤ ¤¤¤¤
3,5
¤¤¤ ¤¤¤¤¤
4,1
¤¤¤¤ ¤
4,2
¤¤¤¤ ¤¤
4,3
¤¤¤¤ ¤¤¤
4,4
¤¤¤¤ ¤¤¤¤
4,5
¤¤¤¤ ¤¤¤¤¤
=
Must cycle keyswitch to clear.
❊
=
Must use programmer to clear, as follows: select Program menu,
†
alter data value of any parameter, cycle keyswitch.
¤ ¤ ¤ ¤ ¤ ¤
( 1 , 4 )
FAULT
no power or defective controller
controller powered up; no faults
THERMAL FAULT
THROTTLE FAULT
SPEED POT FAULT
UNDERVOLTAGE FAULT
OVERVOLTAGE FAULT
MAIN OFF FAULT
(not used)
MAIN FAULT ❊
MAIN ON FAULT
(not used)
WIRING FAULT ❊
BRAKE ON FAULT
PRECHARGE FAULT ❊
BRAKE OFF FAULT
HPD FAULT
CURRENT SENSE FAULT ❊
HARDWARE FAILSAFE ❊
EE CHECKSUM FAULT †
(not used)
BATTERY DISCONNECT FAULT ❊
¤ ¤ ¤ ¤
( 1 , 4 )
