Checking the seal on the doors

Operating Instructions SP Dual compact | B1500016_en
The example below shows how to check the seal on the fuel loading door. The
procedure is the same for checking the seal on the combustion chamber door.
❒ Insert a sheet of paper at the side of the door stop at the top between the door and
the boiler
❒ Close the door
❒ Try to pull out the sheets of paper.
➥ If the paper cannot be removed:
The door seal is OK and the settings are correct
➥ If the paper can be removed:
The door is not sealed properly and must be adjusted
Increase the contact pressure at the locking cam:
⇨ See "Positioning the doors" [page 46]
❒ Check the seal again after positioning the doors
❒ Repeat the procedure at the side of the door stop at the bottom and at the side of
the door handle
