4.2.4 Annual maintenance

Checking the primary air openings

Cleaning the carbonisation gas duct

Checking the seal on the doors

Cleaning the flue gas pipe

Checking the draught limiter and explosion flap (if present)

Page 24
B0610008
Open the insulated door and the
fuel loading chamber door
Unhinge the cladding plates
Check the primary air openings (C)
for unobstructed air-flow
If necessary, clean the openings
Open the insulated door and the
fuel loading chamber door
Clean the carbonisation gas duct
with a small brush
Switch off the induced draught
fan, to avoid damage to the
induced draught fan by the
brush
Close the relevant door and check
its seal
Check seal (D) for perfect
alignment on the door frame
Imprint in the seal
If the seal is coloured black at several
points or the imprint is disjointed:
The seal is no longer efficient.
Tighten the door latches or
replace the seal
Clean the pipe connecting the boiler and the chimney with a
chimney sweeping brush
Depending on the layout of the flue pipes and the chimney
draught cleaning yearly may not be enough!
Check the draught limiter and explosion flap for ease of operation
Boiler servicing
Inspection, cleaning and maintenance
D
C
I
