4.4.3 Performing the emissions measurement in firewood mode

General information on measurement

Create the measurement conditions and perform the measurement

48
Emissions measurement by chimney sweep or regulatory body
Observe the following basic conditions:
❒ Only use fuel permitted according to the operating instructions
➥ Ensure that the water content (w) is greater than 15% and less than 25%
❒ Use short split wood (edge length EL < 10 cm) to create the measuring conditions
and for the measurement itself
❒ The fuel must be dry, clean and uncontaminated (not painted, glued, etc.)
❒ The combustion process must not be interrupted during the measurement
Interruptions to the combustion process include:
- Opening the boiler doors
- Stoking the burning material
- Switching off the ID fan (e.g. because of inadequate heat consumption)
❒ Fill the boiler approx. 1/4 full with short split wood () in accordance with the
operating instructions and heat up
Ensure that the operating conditions are fulfilled:
▪ Return temperature min. 60 °C
▪ Boiler temperature min. 70 °C
▪ Chimney draught ranging from 8 - 10 Pa
❒ Allow the fuel to burn off until a basic firebed is achieved
➥ This will take at least one hour depending on the fuel used and the power
consumption
❒ Open the fuel loading door, distribute the embers evenly with the furnace tool and
gauge the height of the embers
➥ The top row of holes in the combustion chamber guards is visible
❒ Close the fuel loading door
Fröling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
Short split wood with an edge length EL < 10 cm
The term "short split wood" has been defined in these
instructions by Froling; there is no fuel standard or similar
guidelines for this.
