Troubleshooting

General fault with power supply

5.2 General fault with power supply

5.2.1 Behaviour of system after a power failure

5.3 Excessive temperature

Operating Instructions SP Dual compact | B1500016_en
Error characteristics
Nothing is shown on the
display
No power to the controller
When the power supply has been restored, the boiler returns to the previous mode
and is controlled according to the specified program.
❒ After a power failure, check whether the STL (high-limit thermostat) has tripped.
❒ Keep the doors of the boiler closed during and after the power failure, at least until
the induced draught fan automatically starts up again.
EXCEPTION:
If the boiler operating status was "Heating up", "Pre-heating" or "Ignition" before the
power failure, the boiler follows the shutdown procedure and cleaning commences.
Only then does the boiler switch to "Preparation" operating status and the system
starts up again.
The high-limit thermostat (STL) shuts down the boiler when it reaches a temperature
of 95 - 100°C. The pumps continue to run.
Once the temperature falls below approx. 75°C, the STL can be reset mechanically:
❒ Unscrew the cap on the STB (high-limit thermostat)
❒ Unlock the STL by pressing with a screwdriver
Cause of error
General power failure
Main switch is turned off
FI circuit breaker or line
protection is switched off
Faulty fuse in the controller
5
Elimination of error
Turn on the main switch
Switch on the FI circuit
breaker or line protection
Replace the fuse – note the
amperage (6.3AT)
51
