Safety

Pictograms used

2.2 Pictograms used
Operating Instructions SP Dual compact | B1500016_en
The following symbols are used in the documentation and/or on the boiler to show
what is required and forbidden and to give warnings.
In accordance with the Machinery Directive, signs fitted directly within the danger area
of the boiler indicate immediate hazards or safety procedures. These stickers must not
be removed or covered.
Refer to the operating
instructions
Wear protective gloves
Keep the doors closed
Work under the supervision of a
second person
Unauthorised access prohibited
Warning - hot surface
Warning - hazardous or irritant
materials
Warning of injury to fingers or
hands, automatic fan
Warning of injury to fingers or
hands, gear/chain drive
Hand injury warning
Increased CO concentration
warning
Wear safety shoes
Turn off the main switch
Wear a dust mask
Lock
No fire, open flames or smoking
Warning - hazardous electrical
voltage
Warning - automatic boiler
startup
Warning of injury to fingers or
hands, automatic screw
Warning of injury to fingers or
hands, cutting edge
Warning of injury from being
pulled into rotating shafts
Slipping hazard warning
