Quick Start; Identification And Variants - Danfoss VLTAutomationDrive FC 360 Quick Manual

Quick Start

1 Quick Start
WARNING
Improper use could result in death, serious injury,
equipment, or property damage. Before installing or using
the equipment, read 1 Safety and 3 Installation carefully!

1.1 Identification and Variants

Confirm that the equipment matches the requirements
and ordering information by checking power size, voltage
and overload data on the name plate of the frequency
converter.
VLT
AutomationDrive
1
R
www.danfoss.com
T/C: FC-360HK37T4E20H2BXCDXXSXXXXAXBX
2
P/N: 134F2970 S/N: 691950A240
0.37 kW 0.5HP High Overload
IN: 3x380-480V 50/60Hz 1.24/0.99A
o
OUT: 3x0-Vin 0-500Hz 1.2/1.1A(Tamb. 45 C)
3
CHASSIS/IP20
CAUTION:
SEE MANUAL
WARNING:
STORED CHARGE DO NOT TOUCH UNTIL 4 MIN. AFTER
DISCONNECTION
RISK OF ELECTRIC SHOCK-DUAL SUPPLY DISCONNECT MAINS
AND LAODSHARING BEFORE SERVICE
Illustration 1.1 Name Plate 1 and 2
1) Typecode
2) Ordering Number
3) Specifications
1 2 3 4 5 6 7
F C - 3 6 0 H
Q
Illustration 1.2 Typecode string
®
VLT AutomationDrive FC 360 Quick Guide
MADE BY DANFOSS
IN CHINA
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
T 4 E 2 0 H
®
MG06A102 - VLT is a registered Danfoss trademark
1-6: Product Name
7: Overload
8-10: Power Size
11-12: Voltage Class
13-15: IP Class
16-17: RFI
18: Braking Chopper
19: LCP
20: PCB Coating
21: Mains Terminals
29-30: Embedded Fieldbus
Table 1.1 Type Code: Selection of Different Features and Options
See for options and accessories.
1) Only 11-75 kW for Normal Duty variants. Fieldbus unavailable for
Normal Duty.
2) For all power sizes see 2.4 Frame Sizes and Power Ratings
3) Not available yet.
4) 0.37-22 kW with built-in braking chopper. 30-75 kW external
braking chopper only.
23 24 25 26 27 28
2 X X C D X X S X
B
H: Heavy Duty
1)
Q: Normal Duty
0.37-75 kW e.g.
2)
K37: 0.37 kW
1K1: 1.1 kW
11K: 11 kW etc.
4: 380-480 V
E20: IP20
H2: C3 Class
X: No
4)
B: Built-in
X: No
3: 3C3
D: Load Sharing
AX: No
3)
A0: Profibus
3)
AL: Profinet
29 30 31 32
X X X A X B X
A 0
A L
1 1
3
