Chapter 2 — Con guring the PB51
Using Extended Test Mode
Use Extended Test mode to run additional diagnostic tests, including
printing speci c test labels, entering Dump mode, and resetting to
factory defaults.
Sample Extended Test Mode Screen
To enter Extended Test mode
1 Make sure that the printer is loaded with media.
2 Press the media cover release button to open the me dia cover.
3 Press the Standby button to turn the printer o .
4 Press Feed and Standby buttons at the same time until CLOSE
5 Close the media cover. You are now in Extended Test mode.
Options in Extended Test Mode
Function
Select Media
Test Labels
22
TEST LABELS
CHESS
PRINTER DOOR appears on the screen.
Press to cycle through the options.
Press to select a test option.
Press to exit Extended Test mode.
Description
This option is almost the same as the
process in Test mode, except that the
printer performs a slow test feed in
Extended Test mode. The slow test feed
enables the printer to perform a slow
sensor calibration which can help resolve
gap or mark detection problems.
This option allows you to print test labels
one at a time. Press
label.
PB51 Mobile Label and Receipt Printer User's Guide
to print the next
