Checks And Inspections; Dashboard - APRILIA PEGASO 650 STRADA Service Station Manual

Electrical system
43.Coil
44.ECU
45.Right turn indicator
46.Low-beam bulb
47.Tail light bulb
48.High-beam bulb
49.Front headlamp
50.Left front turn indicator
51.Self-diagnosis connector
52.Diode
53.Diode module
Cable colour:
Ar orange
Az sky blue
B blue
Bi white
G yellow
Gr grey
M brown
N black
R red
Ro pink
V green
Vi purple

Checks and inspections

Dashboard

INSTRUMENT PANEL OPERATION
By turning the ignition key to KEY ON, the follow-
ing indicators on the instrument panel are lit for two
seconds:
•
the ''PEGASO 650'' logo
•
all the warning lights except the ''Hea-
ted handgrips warning light''
•
the backlighting;
ELE SYS - 38
PEGASO 650 STRADA - TRAIL - FACTORY
