Technical Information
PVG 32 Proportional Valve Group
Modules symbols, description and code numbers

PVM, mechanical actuation

PVM, mechanical actuation
Symbol
PVMD, cover for mechanical actuation
Symbol Description
— PVMD, Cover for purely mechanically operated valve
PVMR, friction detent
Symbol
PVMF, mechanical float position
Symbol
© Danfoss | August 2017
Description
PVM, Standard, spring centered
Individual oil flow adjustment to ports A and B
Without actuation lever and base.
Shaft for mounting of actuation lever
PVM, as standard, witout actuation lever.
With base for mounting of actuation lever
PVM, Standard, spring. Individual oil flow
adjustment to ports A and B. (Anodized)
Description
PVMR, Friction detent
Description
PVMF,
Mechanical float position lock
Code number
with stop screws w/o stop screws
157B3171
157B3173
157B3174
157B3184
Material Code No.
aluminium 157B0001
aluminium 157B0009
cast iron 157B0021
Material Code number
aluminium 157B0004
aluminium 157B0012
cast iron 157B0024
Material Code number
aluminium 157B0005
520L0344 | BC00000038en-US0802 | 57
157B3191
157B3193
157B3194
-
Anodized
no
yes
no
Anodized
no
yes
-
Anodized
no
