PVG 32 Proportional Valve Group
Module selection chart
PVB is with LS shuttle valve
A/B
- 9784 9783 9782
- - - -
- - - -

Standard PC spools

PVB is with LS shuttle valve
A/B
Press. compensated flow: l/min [US gal/min]
E D C B
100 65 40 25
[26.4] [17.2] [10.6] [6.6]
- 7033 7032 7031
7134 7133 7132 7131
7064 7063 7062 7061
© Danfoss | August 2017
Code number 157B....
9781 - -
B A
P T
4-way, 3-position Throttled, open
neutral position
- - -
4-way, 3-position Throttled, A → T in
neutral position
- - -
4-way, 3-position B → T in neutral
position
Code number 157B....
ISO symbol
A AA
10 5
[2.6] [1.3]
7030 7035
4-way, 3-position
Closed neutral position, PC → A and B
7130 7135
4-way, 3-position Throttled, open neutral position,
PC → A and B
- -
4-way, 3-position
Closed neutral position, PC → A
157-03.11
Symbol
PVB is without LS shuttle valve
A/B
- 9760 9761 9762 9763
- - - - -
- - - - -
PVB is without LS shuttle valve
A/B
Press. compensated flow: l/min [US gal/min]
AA A B C
5 10 25 40
[1.3] [2.6] [6.6] [10.6]
7015 7010 7011 7012
7115 7110 7111 7112
- 7040 7041 7042
520L0344 | BC00000038en-US0802 | 63
9764 -
9794 -
9804 -
D E
65 100
[17.2] [26.4]
7013 -
7113 -
7043 7044
