Pvea, Pveh, Pves, Pveu; Pvep; Pved-Cc And Pved-Cx - Danfoss PVG 32 Technical Information

Technical Information
PVG 32 Proportional Valve Group
Electrical actuation

PVEA, PVEH, PVES, PVEU

PVEP

PVED-CC and PVED-CX

© Danfoss | August 2017
Variants:
•
-F for float in B-direction
max. flow B at 4.8 mm
•
-F for float in A-direction
max. flow A at 5.5 mm
•
PVES-SP with spool position feedback
•
Anodized aluminum block
•
ATEX certified
AMP version
PVEA/PVEH/PVES
LED
U
S
Pin no.
U
1
DC
2
3
4
Error
Grey connector
157-500.10
PVEA, PVEH, PVES, PVEU
and PVEH float A
The PVEP is controlled with separate PWM control signals
for A and B direction.
The PVEP has hysteresis and fault monitoring like the
PVES.
Power supply: 11→ 32 V
Connector: Deutsch ®
The CAN controlled PVE embedded microcontrollers support the same high spool controllability as the
PVES and additional has high quality feedbacks, safety monitoring and detailed diagnostics.
PVED has digital communication, that allows a wide range of feedback, setpoint and highly costumized
settings. CAN bus serial communication makes wiring much easier. Only one cable per PVG group.
Power supply: 11→ 32 V
Connectors:
•
AMP
•
DIN/Hirshmann
•
Deutsch ®
DIN/Hirschmann version
PVEH, PVEM, PVES,
PVEH float B and PVEM float B
Deutsch ® version
Not
connected
3
2
Error
1
U s
Deutsch version
®
LED
PVEA, PVEH, PVES, PVEU
and PVEH float B
PVES-SP
LED
Spool position
4
5
6
U
DC
520L0344 | BC00000038en-US0802 | 33
