Technical Information
PVG 32 Proportional Valve Group

Technical characteristics

General

PVP, pump side module

PVB, basic modules oil flow characteristics

36 | © Danfoss | August 2017
The characteristics in this catalog are typical measured values. During measuring a mineral based
hydraulic oil with a viscosity of 21 mm2/s [102 SUS] at a temperature of 50°C [122°F] was used.
Pressure relief valve characteristic in PVP
The pressure relief valve is set at an oil flow of 15 l/min [4.0 US gal/min].
Setting range:
•
30 to 350 bar [435 to 5075 psi] with PVSI end plate
•
30 to 300 bar [435 to 4351 psi] with PVS end plate
Pressure relief valve characteristic
The oil flow for the individual spool depends on:
Neutral by-pass pressure drop characteristic (open
center)
520L0344 | BC00000038en-US0802
