Installation
3
Template Sheet 1
Disassemble the camera. See the section 'Installation -
Disassemble the camera' for details.
2
2
Using the template sheet, make the cabling hole on
the wall/ceiling.
3
Connect the network cable and power cable
respectively. See the section 'Installation - Cabling' for
details.
Put the Lan cable into (a), then (b) will be assembled to (a)
without making any space.
4
on the ceiling.
5
To achieve desired view direction and orientation,
stopper screw.
4
5
6
Attach the dome cover to the bottom case.
Warning:
DO NOT TOUCH THE SURFACE OF THE BUBBLE.
CleanView™ Hydrophobic Dome Coating Repels.
6
8
c
b
a
