Digital Watchdog MEGApix DWC-MV84WiA User Manual page 24

Setup -
Video Configuration
1
Live Video Channel Setup
The video can be configured to variety settings with a
combination of codec and resolution.
The camera performance has to be considered when setting
multiple channels. This effects on the performance of the
camera.
2
Codec
Choose the video codec. According to the selected codec,
the subcategories can be changed automatically.
3
Description
Input the additional description about the selected channel.
Max. 30 alphabets are allowed(Including space). For the
description, English Alphabets, numbers and special
characters ( - _ @ . ) can be used.
4
Resolution
Select the video resolution.
Available resolution can be depends on the codec setup between
the channels.
NTSC
4M 2560 x 1440
3M
2304 x 1296
1080p/i 1920 x 1080
720p/i 1280 x 720
SVGA 800 x 600
VGA 640 x 480
704 x 576
4CIF
704 x 480
352 x 288
CIF
352 x 240
<Resolution of Video Format>
5
Frame Rate
Select the maximum Frame Rate.
Available Frame Rate can be different although same codecs
were set up.
24
1
2
3
4
5
PAL
2560 x 1440
2304 x 1296
1920 x 1080
1280 x 720
800 x 600
640 x 480
704 x 576
704 x 480
352 x 288
352 x 240
