Digital Watchdog MEGApix DWC-MV84WiA User Manual page 43

Setup -
FTP Settings
7
To transfer / save the image to the relevant sites through FTP,
then FTP needs to be setup.
1
General Setting
FTP function can be enable or disable.
2
FTP Server Address
Define FTP Server IP Address. If IP Address form is incorrect,
a Message box will be shown to try again.
3
FTP Upload Path
Define a path in FTP server to store video. For the path name,
English Alphabets, numbers and special characters ( / ~ !@ $
^ ( ) _ - { } [ ] ; , ) can be used.
4
FTP Port
Define the FTP Server Port. If Port is not appropriate, it is
impossible to access to FTP Server.
5
User ID
Define User ID to access to the FTP Server. Fill out the correct
User ID registered in the FTP Server.
6
Password
Define Password to access to the FTP Server. Fill out the
correct Password registered in the FTP Server.
7
Click 'Apply' to make above setting effective.
Refer the above screen image for the example.
43
1
2
3
4
5
6
