DWC-MVH2I4WV
MEGApix® Outdoor Dome Camera
Before installing or operating the camera, please read and follow this manual carefully.
08/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWC-MVH2I4WV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Watchdog DWC-MVH2I4WV

Summary of Contents for Digital Watchdog DWC-MVH2I4WV

  • Page 1 DWC-MVH2I4WV MEGApix® Outdoor Dome Camera Before installing or operating the camera, please read and follow this manual carefully. 08/18...
  • Page 2 PRECAUTIONS  Do not open or modify.  Do not open the case except during maintenance and installation, for it may be dangerous and can cause damages.  Do not put objects into the unit.  Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS* Introduction..................................4 Features.........................................4 Parts ........................................5 Dimensions......................................6 Inside the Box ....................................7 Installation..................................8 Network Connection ..................................8 Before Installation .....................................9 Installation ......................................10 Adjusting the Camera’s Angle ..............................11 MEGApix® 1080p™ Camera Setup..........................12 Installing DW Desktop Tool™ ...............................12 Using DW Desktop Tool™ ................................13-15 Network Options....................................16 Camera Reboot....................................17 MEGApix®...

  • Page 4: Introduction

    FEATURES*  1/2.8” CMOS Image Sensor  Real-time 2.1MP Resolution, 1080P at 30fps  Dual Codecs (H.264, MJPEG) with Simultaneous Streaming  4.0mm Fixed Lens  Smart IR™ with Intelligent Camera Sync. 100ft Range  Smart DNR™ 3D Digital Noise Reduction ...

  • Page 5: Parts

    PARTS & DESCRIPTIONS* Description Mounting Base Horizontal Stand Vertical Stand Bubble Network Interface Power Interface IR LED Lens Black Liner Safety Rope...

  • Page 6: Dimensions

    DIMENSIONS*...

  • Page 7: Inside The Box

    INSIDE THE BOX * The following items are included with the MEGApix® 1080p™ camera. Drill Template Hole A: for cables routed through the ceiling screw hole 1: for Mounting Base Mounting Template...

  • Page 8: Installation

    NETWORK CONNECTION* T h e r e a r e t w o w a y s t o p o w e r a M E G A p i x ® 1 0 8 0 p ™ c a m e r a . U s e a P o E - e n a b l e d s w i t c h t o c o n n e c t d a t a a n d p o w e r t h r o u g h a s i n g l e c a b l e a n d b e g i n v i e w i n g a n d r e c o r d i n g i m a g e s i n s t a n t l y .

  • Page 9: Before Installation

    INSTALLATION* B e f o r e S t a r t i n g t h e I n s t a l l a t i o n  Make sure the device in the package is in good condition and all the assembly parts are included.

  • Page 10: Installation

    INSTALLATION* I n s t a l l i n g t h e C a m e r a 1. Detach the camera’s cover dome from the camera’s module by unscrewing the three cover dome screws. 2. Use the mounting template or camera itself to mark and drill the holes in the mounting template.

  • Page 11: Adjusting The Camera's Angle

    INSTALLATION* A d j u s t i n g t h e C a m e r a ’ s A n g l e The camera supports 3-axis adjustment. Loosen the tilt adjust screw to adjust the tilt angle [0°~75°], hold the black liner to adjust the pan angle [0°~355°], and hold the lens to rotate the camera [0°~355°].

  • Page 12: Megapix® 1080P™ Camera Setup

    PC. When setup is complete, launch DW Desktop Tool. The software will automatically search your network for all Digital Watchdog® supported devices. Your camera will appear as ”DWC-MVH2I4WV.” Double-click on the camera name and select ‘View Camera Website’ to launch the camera’ web viewer.

  • Page 13: Using Dw Desktop Tool

    DW Desktop Tool™ * U s i n g D W D e s k t o p To o l ™ S o f t w a r e U s e D W D e s k t o p To o l ™ t o c h a n g e t h e b a s i c s e t t i n g s o f y o u r M E G A p i x ® 1 0 8 0 p ™...
  • Page 14 DW Desktop Tool™ * U s i n g I P F i n d e r S o f t w a r e U s e I P F i n d e r t o s e t t h e c o n n e c t i o n t y p e a n d t h e I P a d d r e s s i n f o r m a t i o n f o r y o u r M E G A p i x ®...
  • Page 15 DW Desktop Tool™ * D H C P The Dynamic Host Configuration Protocol (DHCP) is a network configuration protocol that allows a device to configure automatically according to the network it is connected to. If your network supports DHCP and your MEGApix® 1080p™ camera is set to DHCP, IP Finder will automatically find and set your MEGApix®...

  • Page 16: Network Options

    DW Desktop Tool™ * U p g r a d i n g C a m e r a s u s i n g t h e D W D e s k t o p To o l U s e t h e D W D e s k t o p To o l ™...

  • Page 17: Camera Reboot

    CAMERA REBOOT* R e s e t t i n g t h e C a m e r a P r e s s R E S E T f o r a b o u t 1 0 s w h e n t h e c a m e r a i s p o w e r i n g o n o r r e b o o t i n g t o r e s t o r e t h e d e f a u l t s e t t i n g s , i n c l u d i n g t h e u s e r n a m e , p a s s w o r d , I P a d d r e s s , p o r t N o .

  • Page 18: Megapix® 1080P™ Camera Web Viewer

    WEBVIEWER* R e m o t e V i d e o M o n i t o r i n g V i a I n t e r n e t E x p l o r e r M o n i t o r a n d c o n f i g u r e t h e M E G A p i x ®...

  • Page 19: Gui Description

    WEBVIEWER* G U I D e s c r i p t i o n M o n i t o r a n d c o n f i g u r e t h e M E G A p i x ® 1 0 8 0 p ™ c a m e r a t h r o u g h a b u i l t - i n w e b v i e w e r.

  • Page 20: First & Second Stream

    WEBVIEWER* F i r s t S t r e a m & S e c o n d S t r e a m C o n f i g u r e u p t o t w o ( 2 ) s t r e a m s e t t i n g s f o r m o n i t o r i n g a n d r e c o r d i n g . On the main monitoring page, user can view the camera with the First Stream settings or secondary Stream settings.

  • Page 21: Megapix® 1080P™ Camera Setup

    WEBVIEWER* S E T U P > LO C A L C O N F I G U R AT I O N S e t u p t h e c a m e r a ’ s P r o t o c o l a n d L i v e P e r f o r m a n c e O p t i o n s . Protocol: On this page, you can update the camera’s streaming protocol.

  • Page 22: Basic > System Settings

    • Device Name: You can rename the camera as needed. By default, the camera’s model will be the camera’s name. • Model: Displays the camera’s model name (DWC-MVH2I4WV) • Firmware and Encoding Version: View the camera’s current firmware and encoding versions. To update the camera’s firmware, see page 24 ‘Maintenance’.
  • Page 23 WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > S Y S T E M > T I M E S E T T I N G S S e t t h e c a m e r a ’...
  • Page 24 WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > S Y S T E M > M A I N T E N A N C E U s e t h i s m e n u o p t i o n t o r e b o o t t h e c a m e r a , r e s e t a n d u p d a t e f i r m w a r e .

  • Page 25: Basic > Network Settings

    WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > N E T W O R K > T C P / I P U s e t h i s m e n u o p t i o n t o s e t u p t h e c a m e r a ’ s n e t w o r k s e t t i n g s . Set the camera’s IP address, subnet mask, gateway and DNS server information.
  • Page 26 WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > N E T W O R K > T C P / I P U s e t h i s m e n u o p t i o n t o s e t u p t h e c a m e r a ’ s n e t w o r k s e t t i n g s . Set the camera’s IP address, subnet mask, gateway and DNS server information.
  • Page 27 WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > N E T W O R K > P O R T U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’ s n e t w o r k p o r t s a s n e e d e d . Set the HTTP port, RTSP port, HTTPS port and server port of the camera.

  • Page 28: Basic > Stream Settings

    WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > S T R E A M S E T T I N G S U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’ s f i r s t a n d s e c o n d s t r e a m s . The camera supports two simultaneous streams.
  • Page 29 WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > S T R E A M S E T T I N G S U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’ s f i r s t a n d s e c o n d s t r e a m s . The camera supports two simultaneous streams.

  • Page 30: Basic > Image Settings

    WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > I M AG E > D I S P L AY S E T T I N G S U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’...
  • Page 31 WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > I M AG E > D I S P L AY S E T T I N G S U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’...

  • Page 32: Basic > Security

    WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > I M AG E > D I S P L AY S E T T I N G S U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’...

  • Page 33: Advanced > Image

    WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > I M AG E > D I S P L AY S E T T I N G S U s e t h i s m e n u o p t i o n t o a d j u s t t h e c a m e r a ’...

  • Page 34: Advances > Security

    WEBVIEWER* S E T U P > B A S I C C O N F I G U R AT I O N > S E C U R I T Y > U S E R U s e t h i s m e n u o p t i o n t o a d d , e d i t , o r d e l e t e u s e r s . The camera can be accessed by different user levels, with different permissions and access to allow for maximum security, preventing people from accessing the camera’s sensitive information.
  • Page 35 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > I M AG E > P R I VAC Y M A S K T h i s m e n u a l l o w s y o u t o s e t u p p r i v a c y m a s k s o v e r s e n s i t i v e r e g i o n s o f t h e c a m e r a ’...
  • Page 36 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > S E C U R I T Y > A U T H E N T I C AT I O N T h i s m e n u a l l o w s y o u t o s e t u p a s e c u r e d l i v e s t r e a m f r o m t h e c a m e r a .
  • Page 37 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > S E C U R I T Y > A N O N Y M O U S V I S I T T h i s s e t u p a l l o w s u s e r w i t h n o u s e r n a m e a n d p a s s w o r d t o a c c e s s t h e c a m e r a .
  • Page 38 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > S E C U R I T Y > I P A D D R E S S F I LT E R U s e t h i s m e n u t o f i l t e r w h a t I P a d d r e s s e s a r e f o r b i d d e n o r p e r m i t t e d t o a c c e s s t h e c a m e r a .
  • Page 39 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > S E C U R I T Y > S E C U R I T Y S E R V I C E U s e t h i s m e n u t o e n a b l e t h e r e m o t e l o g i n , a n d i m p r o v e t h e d a t a c o m m u n i c a t i o n s e c u r i t y.

  • Page 40: Advanced > Basic Event

    WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > B A S I C E V E N T > M O T I O N D E T E C T I O N M o t i o n d e t e c t i o n d e t e c t s t h e m o v i n g o b j e c t s i n t h e c o n f i g u r e d s u r v e i l l a n c e a r e a , a n d a s e r i e s o f a c t i o n s c a n b e t a k e n w h e n t h e a l a r m i s t r i g g e r e d .
  • Page 41 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > B A S I C E V E N T > M O T I O N D E T E C T I O N M o t i o n d e t e c t i o n d e t e c t s t h e m o v i n g o b j e c t s i n t h e c o n f i g u r e d s u r v e i l l a n c e a r e a , a n d a s e r i e s o f a c t i o n s c a n b e t a k e n w h e n t h e a l a r m i s t r i g g e r e d .
  • Page 42 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > B A S I C E V E N T > M O T I O N D E T E C T I O N M o t i o n d e t e c t i o n d e t e c t s t h e m o v i n g o b j e c t s i n t h e c o n f i g u r e d s u r v e i l l a n c e a r e a , a n d a s e r i e s o f a c t i o n s c a n b e t a k e n w h e n t h e a l a r m i s t r i g g e r e d .
  • Page 43 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > B A S I C E V E N T > M O T I O N D E T E C T I O N M o t i o n d e t e c t i o n d e t e c t s t h e m o v i n g o b j e c t s i n t h e c o n f i g u r e d s u r v e i l l a n c e a r e a , a n d a s e r i e s o f a c t i o n s c a n b e t a k e n w h e n t h e a l a r m i s t r i g g e r e d .
  • Page 44 WEBVIEWER* S E T U P > A D VA N C E D C O N F I G U R AT I O N > B A S I C E V E N T > M O T I O N D E T E C T I O N M o t i o n d e t e c t i o n d e t e c t s t h e m o v i n g o b j e c t s i n t h e c o n f i g u r e d s u r v e i l l a n c e a r e a , a n d a s e r i e s o f a c t i o n s c a n b e t a k e n w h e n t h e a l a r m i s t r i g g e r e d .

  • Page 45: Specifications

    SPECIFICATIONS* IMAGE Image Sensor 1/2.8” progressive scan CMOS F1.2 (30IRE): 0.01 Lux [Color] (AGC ON) Minimum Scene Illumination F1.2 (30IRE): 0.00 Lux [B/W] Focal Length 4.0mm 85° Angle of View Lens Type Fixed Lens IR Distance 100ft Smart IR™ OPERATIONAL Shutter Speed 1/3s ~ 1/100000s Smart DNR™...
  • Page 46 SPECIFICATIONS* ENVIRONMENTAL Operating Temperature -30 °C ~ 60 °C (-22°F ~ 140 °F) Operating Humidity Less than 90% (Non-Condensing) IP Rating IP66 Certified (Protects against dust and high pressure water) Other Specifications CE, FCC, RoHS Electrical Power Requirement DV12V, PoE [IEEE802.3af, Class 2] LED Off: 5W, 416mA Power Consumption LED On: 7W, 583mA...

  • Page 47: Troubleshooting

    TROUBLESHOOTING Before sending your camera for repair, check the following or contact your technical specialist. I c a n ’ t f i n d m y M E G A p i x ® 1 0 8 0 p ™ c a m e r a o n t h e I P F i n d e r s o f t w a r e . ...
  • Page 48 TROUBLESHOOTING Before sending your camera for repair, check the following or contact your technical specialist. I c a n ’ t c o n n e c t t o m y M E G A p i x ® 1 0 8 0 p ™ c a m e r a t h r o u g h t h e W e b B r o w s e r ...
  • Page 49 TROUBLESHOOTING Before sending your camera for repair, check the following or contact your technical specialist. I c a n ’ t s e e t h e l i v e v i d e o o f m y M E G A p i x ® 1 0 8 0 p ™ c a m e r a . ...
  • Page 50 TROUBLESHOOTING Before sending your camera for repair, check the following or contact your technical specialist. S e t t i n g t h e I P A d d r e s s f o r y o u r P C Dynamic Host Configuration Protocol (DHCP) is the default setting for the camera.

  • Page 51: Warranty

    WARRANTY INFORMATION* Digital Watchdog (referred to as “the Warrantor”) warrants the Camera against defects in materials or workmanships as follows: Labor: For the initial two (2) years from the date of original purchase if the camera is determined to be defective, the Warrantor will repair or replace the unit with new or refurbished product at its option, at no charge.

  • Page 52: Limits & Exclusions

    This warranty gives you specific legal rights, and you may also have other rights from vary from state to state. If the problem is not handled to your satisfaction, then write to the following address: Digital Watchdog, Inc. ATTN: RMA Department 5436 W Crenshaw St...
  • Page 53 Headquarters Office: 5436 W Crenshaw St, Tampa, FL 33634 Sales Office: 16220 Bloomfield Ave., Cerritos, California, USA 90703 PH: 866-446-3595 | FAX: 813-888-9262 www.Digital-Watchdog.com technicalsupport@dwcc.tv Technical Support PH: USA & Canada 1+ (866) 446-3595 International 1+ (813) 888-9555 French Canadian 1+ (514) 360-1309 Technical Support Hours: Monday-Friday 9:00am to 8:00pm Eastern Standard Time...
