Setup -

IP Address Filter Configuration

3
6
1 IP Address Filter
IP filter function can be enable or disable.
2
IP Filter Type
The address in the list of Filtered IP Address will be allowed
or denied access to this product.
if select Deny, all ip address can't access without in the list of IP
Addresses.
3
Click 'Apply' to make above setting effective.
4
Filtered IP Address
Display the filterd IP address.
5
IP Address
Define the IP address you want to apply the IP filter.
6
Click 'Add' to add the ip address to the list.
Click 'Remove' to remove the ip address selected in the list.
Click 'Remove All' to remove all ip in the list.
60
