Installation -
Installation Using Mount Bolt & Nut
4
Insert the mount bolts into template holes after
connecting the cable.
5
Fix the bottom case by tightening mount nuts to
mount bolts on the ceiling panel.
6
To achieve desired view direction and orientation,
stopper screw.
7
Attach the dome cover to the bottom case.
Warning:
DO NOT TOUCH THE SURFACE OF THE BUBBLE.
CleanView™ Hydrophobic Dome Coating Repels.
11
