Service instruction
6 .
Assembling the
vane pump
Disassembling and assembling iSave 21
6.
Side plate removed.
8.
Remove vanes.
1.
Position the guide pin.
180R9219 / 521B1171 / DKCFN.PI.003.K3.02 / 11.2013
7.
Gently remove the rotor.
Note: Loose parts inside the rotor.
9.
Gently remove side plate.
2.
Location hole in the side plate:
13
