Service instruction
8
Disassembling and assembling iSave 21
6.
Mount the high-pressure bearing
8.
Remove old O-ring with a new one
10.
Mount all bolts in the flange and tighten
them all with 30Nm±3
11
180R9219 / 521B1171 / DKCFN.PI.003.K3.02 / 11.2013
7.
Tighten the high-pressure bearing using
special socket and torque wrench with
70Nm±7
9.
Position the housing over the guide pin
