Web Page Item
Door Open Timeout (in seconds)
Door Sensor Normally Closed
Intrusion Sensor
Flash Button LED*
Activate Relay
Play Audio Locally
Play Audio Remotely
Dial Out Extension
3. After changing the parameters, click Save Settings.
Operations Guide
Table 2-8. Sensor Setup Parameters
Description
Select the number of seconds that you want to pass before
the door sensor is activated.
Select the inactive state of the door sensors.
Select Yes to flash the LED until the sensor is deactivated
(roughly 10 times/second).
Select Yes to activate the relay until the sensor is
deactivated.
Select Yes to loop an audio file out of the Interfom speaker
until the sensor is deactivated.
Select Yes to call a preset extension and play a pre-
recorded audio file (once).
Enter the button dial-out extension number.
Click this button to save your configuration settings.
Changing a parameter that has an asterisk next to it will
cause a system reboot when saved.
Link to the Intercom Setup page.
Link to the Network Setup page.
Link to the Upgrade Firmware page.
Link to the Home page.
