This section makes it easier for you to specify and
order a VLT 2800.
Choice of frequency converter
The frequency converter must be chosen on the
basis of the present motor current at maximum
loading of the unit. The frequency converter's rated
output current I must be equal to or greater than
INV.
the required motor current.
Mains voltage
VLT 2800 is available for two mains voltage
ranges: 200-240 V and 380-480 V.
Select whether the frequency converter is
connected to a mains voltage of:
1 x 220 - 240 Volt mains voltage
Typical shaft output
P
INV.
Type [kW]
2803 0.37
2805 0.55
2807 0.75
2811 1.1
2815 1.5
3 x 200 - 240 Volt mains voltage
Typical shaft output
P
INV.
Type [kW]
2803 0.37
2805 0.55
2807 0.75
2811 1.1
2815 1.5
2822 2.2
2840 3.7
MG.28.E9.02 - VLT is a registered Danfoss trademark
- 1 x 220 - 240 V single-phase AC voltage
- 3 x 200 - 240 V three-phase AC voltage
- 3 x 380 - 480 V three-phase AC voltage
Max. constant output
current I
[HP]
0.5 2.2
0.75 3.2
1.0 4.2
1.5 6.0
2.0 6.8
Max. constant output
current I
[HP]
0.5 2.2
0.75 3.2
1.0 4.2
1.5 6.0
2.0 6.8
3.0 9.6
5.0 16.0
®
VLT 2800 Series
Max. constant output power
INV.
[A]
Max. constant output power
INV.
[A]
at 230 V S
INV.
[kVA]
0.9
1.3
1.7
2.4
2.7
at 230 V S
INV.
[kVA]
0.9
1.3
1.7
2.4
2.7
3.8
6.4
