Danfoss VT2800 Series Design Manual page 35

Operating data
Resulting reference
Resulting reference
Feedback
Output frequency
Output frequency x scaling
Motor current
Torque
Power
Power
Motor voltage
DC link voltage
Thermal load motor
Thermal load
Hours run
Digital input
Pulse reference
External reference
Status word
Heatsink temperature
Alarm word
Control word
Warning word
Extended status word
Analogue input 53
Analogue input 60
Three operating data items can be shown in the
first display line, and one operating variable can be
shown in the second display line. Is programmed via
parameters 009, 010, 011 and 012 Display readout .
Display modes
The LCP control unit has different display
modes, which depend on the mode selected
for the frequency converter.
Display mode I:
This display mode is standard after startup
or initialisation.
FREQUENCY
50.0 Hz
MOTOR IS RUNNING
Line 2 shows the data value of an operating data item
with unit, and line 1 contains a text that explains line
2. In the example, Frequency has been selected as
readout via parameter 009 Large display readout. In
normal operation, another variable can be entered
immediately using the [+ / -] keys.
Display mode II:
Switch between Display modes I and II is performed
by briefly pressing the [DISPLAY / STATUS] key.
MG.28.E9.02 - VLT is a registered Danfoss trademark
Unit
[%]
[unit]
[unit]
[Hz]
[-]
[A]
[%]
In this mode, all data values for four operating
[kW]
data items with any pertaining units are shown,
[HP]
[V]
see table. In the example, the following have been
[V]
selected: Frequency, Reference, Torque and Current
[%]
as readout in the first and second line.
[%]
[hours]
Display mode III:
[binary]
[Hz] This display mode is called up as long as the [DISPLAY
[%]
/ STATUS] key is held down. When the key is released
[hex]
it switches back to Display mode II, unless the key is
[°C]
held down for less than approx. 1 sec., in which case
[hex]
[hex]
the system always reverts to Display mode I.
[hex]
[hex]
[V]
[mA]
Here you can read out the parameter names and
units for operating data in the first and second lines.
Line 2 in the display remains unchanged.
®
VLT 2800 Series
24.3% 30.2% 13.8A
50.0 Hz
MOTOR IS RUNNING
REF% TORQUE CURR A
50.0 Hz
SETUP
1
MOTOR IS RUNNING
35
