DC link voltage, parameter 525:
Gi v es the intermediate circuit voltage in the
frequency converter.
Thermal load, motor [%], parameter 526:
Gi v es the calculated/estimated thermal load on
the motor. 100% is the cut-out limit. See also
parameter 128 Thermal motor protection.
Thermal load INV [%], parameter 527:
Gi v es the calculated/estimated thermal load on the
frequency converter. 100% is the cut-out limit.
Digital input, parameter 528:
Gi v es the signal status from the 5 digital inputs (18, 19,
27, 29 and 33). Input 18 corresponds to the bit on the
extreme left. '0' = no signal, '1' = connected signal.
Terminal 53 analogue input [V], parameter 529:
Gi v es the voltage value for the signal on terminal 53.
Terminal 60 analogue input [mA], parameter 531:
Gi v es the present value for the signal on terminal 60.
Pulse reference [Hz], parameter 532:
Gi v es a pulse frequency in Hz connected to terminal 33.
External reference, parameter 533:
Gi v es the sum of external references as a percentage
(sum of analogue/pulse/serial communication)
in the range from Minimum reference, Ref
to Maximum reference, Ref
Status word, parameter 534:
Gi v es the present status word for the frequency
converter in Hex. See Serial communication
for the VLT 2800.
Bus feedback 1, parameter 535:
Allows writing of a bus feedback value which will
then form part of the feedback handling.
Inverter temperature, parameter 537:
Gi v es the present inverter temperature on the
frequency converter. The cut-out limit is 90-100
°C, with cut back in at 70 ± 5 °C.
Alarm word, parameter 538:
Gi v es in Hex code which alarm is on the
frequency converter. See Warning word, extended
status word and alarm word.
Control word, parameter 539:
Gi v es the present control word on the frequency
converter in Hex. See Serial communication
for the VLT 2800.
Warning word, parameter 540:
